| Processor & Chipset | - Intel® Pentium® dual-core mobile processor with up to 1 MB L2 cache, supporting Intel® 64 architecture
- Mobile Intel® GL40 Express Chipset
|
| Memory | - DDR2 memory, upgradeable to 4 GB using dual soDIMM modules (dual-channel support)
- * A 64-bit operating system is required to enjoy the ultimate performance of 4 GB memory.
|
| HDD | - S-ATA 160GB Hard Disk Drive with Acer DASP (Disk Anti-Shock Protection)
|
| Storage | - DVD-Super Multi double-layer drive or, DVD/CD-RW combo drive
- 5-in-1 card reader, supporting Secure Digital (SD), MultiMediaCard (MMC), Memory Stick® (MS), Memory Stick PRO™ (MS PRO), xD-Picture Card™ (xD)
|
| Display | - 15.4" WXGA high-brightness TFT LCD, 1280 x 800 pixel resolution, supporting simultaneous multi-window viewing via Acer GridVista™
- 16.7 million colours
|
| Graphics | - Mobile Intel® GL40 Express Chipset with integrated 3D graphics, featuring Intel® Graphics Media Accelerator 4500M (Intel® GMA 4500M) with up to 1759 MB of Intel Dynamic Video Memory Technology 5.0 (64 MB of dedicated video memory, up to 1695 MB of shared system memory), supporting Microsoft® DirectX® 10
- Dual independent display support
- MPEG-2/DVD hardware assisted capability
- WMV9 (VC-1) and H.264 (AVC) support (acceleration)
|
| Multimedia | - Two built-in Acer 3DSonic stereo speakers
- High Definition Audio support
- MS-Sound compatible
- Built-in microphone
|
| Communication | - Acer Video Conference featuring Voice and Video over Internet Protocol (VVoIP) support via Acer CrystalEye webcam and optional Acer Xpress VoIP phone
- Integrated Acer CrystalEye webcam, supporting enhanced Acer PrimaLite™ technology (manufacturing option)
- Gigabit Ethernet supporting ASF (Alert Standard Format) 2.0, Wake-on-LAN ready
- Acer InviLink™ Nplify™ 802.11b/g/Draft-N Wi-Fi CERTIFIED® network connection, supporting Acer SignalUp™ wireless technology, or
- Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED® network connection, supporting Acer SignalUp™ wireless technology
- Bluetooth® 2.0+EDR (Enhanced Data Rate) (factory option)
- 56K Modem, Wake-on-Ring ready
|
| I/O Interfaces | - 1x ExpressCard™/34 slot
- 1 x PC Card slot (Type II)
- Acer Bio-Protection fingerprint reader
(manufacturing option) - 5-in-1 card reader (SD, MMC, MS, MS PRO, xD)
- 3 x USB 2.0 ports
- 1 x External display (VGA) port
- 1 x Modem (RJ-11) port
- 1 x Gigabit Ethernet (RJ-45) port
- 1 x Microphone-in jack
- 1 x Line-in jack
- 1x DC-in jack for AC adapter
|
| Security | - Acer Bio-Protection fingerprint solution (on selected models), featuring Pre-Boot Authentication (PBA), computer protection, Acer ProfileLaunch, FingerLaunch, Acer FingerNav
- Enhanced Acer DASP (Disk Anti-Shock Protection) HDD protection technology
- Slot for Kensington lock
- BIOS user and supervisor passwords
|
| Power supply and battery | - ACPI 3.0 CPU power management standard: supports Standby and Hibernation power-saving modes
- 48.8W 6-cell Li-ion battery pack, or 71W 8-cell Li-ion battery pack
- Up to 5-hour battery life with 8-cell, or up to 2.5-hour battery life with 6-cell battery pack
- 3-pin 65W AC adapter
- Energy Star®
|
| Keyboard & Special Controls | - 88-/89-key Acer FineTouch™ keyboard with 5-degree curve, inverted "T" cursor layout, 2.5 mm (minimum) key travel
- 12 function keys; four cursor keys; two Windows® keys; hotkey controls; embedded numeric keypad; international language support
- Empowering Key
- Easy-launch buttons: Internet, email, user-programmable
- Productivity keys: Lock and Sync
- Two front-access switches: WLAN and Bluetooth®
|
| Weight and dimensions | - 360 (W) x 267 (D) x 30.3/43 (H) mm
(14.17 x 10.51 x 1.09/1.69 inches) - 3.02 kg (6.65 lbs.) with 8-cell battery pack
2.88 kg (6.36 lbs.) with 6-cell battery pack
|
| Quality & Reliability Tests | - Temperature & humidity test
- Free drop test
- Acoustics test
- Weight and pressure test
- Spillage test
- Shock and vibration test
- Electrostatic discharge immunity test
- MTBF (Mean Time Between Failure) test
- Hinge life test
- Keyboard-switch life test
|
| Software | - Acer Empowering Technology (Acer eDataSecurity, ePower, eRecovery, eSettings Management)
- Acer Crystal Eye
- Acer GridVista™
- Acer Launch Manager
- Adobe Reader™
- Corel® WinDVD
- NTI® Media Maker™ / NTI® Shadow™
- McAfee Internet Security Suite 60-day trial version (or equivalent)
- Microsoft® Office Ready 2007
|
| Options | - Acer Xpress VoIP phone featuring Acer Video Conference Manager
- Additional memory modules
- Additional battery pack
- Additional AC adapter
- External USB floppy disk drive
|
| Certifications | - Wi-Fi®
- ACPI 3.0
- Mobile PC 2002
- DMI 2.0
|
