Adjustable IR Pyroelectric Infrared PIR Motion Detector / Sensor Module (Arduino Compatible)..!

Adjustable IR Pyroelectric Infrared PIR Motion Detector / Sensor Module for Electronics DIY, Development & Projects (Arduino Compatible)..!

Technical Information

Key Features

These little module is perfect for robotics or any other motion sensing application.
Distance and delay time can both be set using the adjustment screws on the side of the device.

Color: White + Green
Infrared sensor with control circuit board
The sensitivity and holding time can be adjusted
Working Voltage Range: DC 4.5V- 20V
Current drain: <60uA
Voltage Output: High/Low level signal:3.3V TTL output
Detection distance: 3~7M (can be adjusted)
Detection range: <140 degrees
Delay time: 5~200s (can be adjusted, default 5s +-3%)
Blockade time: 2.5 S (default)
Trigger: L: Non-repeatable trigger H: Repeat Trigger (default)
Work temperature: -20 ~ +80 deg C
Trigger Method: L unrepeatable trigger / H repeatable trigger

General Specs

Material: Mixed Material
Dimensions (cm): 3.3 x 2.5 x 1.8 (approx)
Weight (kg): 0.008

Example on how to use this device click
For Arduino code click
