Alto TS412 - 12" 2500W 2-Way Active Speaker w/ Bluetooth

TS412 - 2500-WATT 12-INCH 2-WAY POWERED LOUDSPEAKER WITH BLUETOOTH, DSP & APP CONTROL

Whether you need a powerful vocal PA or club-shaking bass performance for a DJ set, TS4 speakers deliver loud, clear, room-filling sound for any application.  With a 12-inch woofer, and a 1.4-inch compression driver, TS412 delivers 2500W of class-leading power and clarity in equal measure.  Compact, lightweight, and designed for reliability, the new TS4 Series makes it simple to get great live sound at every event.

Features

• 2500 W peak (1600 LF + 900 HF) 1250 W continuous RMS (800 LF + 450 HF)
• FREE Alto App (iOS/Android) for remote configuration and control
• Bluetooth® audio streaming direct from device
• On-board DSP with 4 Speaker Use modes (inc. Custom EQ via App)
• True Wireless Stereo speaker linking via Bluetooth®
• Integrated 3-channel mixer with dual XLR ¼-inch combo inputs, mic/line switches and independent level controls
• XLR Mix output, Speaker Use, and Sub Size Controls
• 12" driver, 2.5" (63 mm) high-temperature voice coil
• 1" exit ceramic driver with 1.4" (35 mm) coil
• Lightweight enclosure for easy transport, set up and installation
• Versatile design - pole-mountable, wedge monitor or flown application with integral M10 suspension points
• Powerful and efficient class D amplifiers with fanless cooling design to run cleaner, quieter and with greater long-term reliability
• Designed and tuned in the USA

Specifications

Output Power

• 2,500W

Low-Frequency Driver

• 12" driver
• 2.5" (63 mm) high-temperature voice coil
• 800W RMS @ 2 ohms

High-Frequency Driver

• 1.0" exit ceramic driver
• 1.4" (35 mm) coil
• 450W @ 4 ohms

Crossover Frequency

• 2kHz

Maximum SPL

• Peak dBSPL @ 1 m: 132dB
• Continuous dBSPL @ 1 m: 129dB

Frequency Response

• 53Hz—20kHz (+/—3dB)

Frequency Range

• 44Hz—20kHz (—10dB)

Horn Coverage

• 90° horizontal x 60° vertical (nominal)

Connectors

• XLR + 1/4" (6.35 mm) TRS combo inputs (balanced): 2
• XLR output (link): 1
• IEC power cable input: 1

Input Impedance Line

• Balanced: 10 kohms
• Unbalanced: 20 kohms
• Mic: 1.2K
• Line Gain/Volume Control Range
• — to 0dB, +4dBu nominal
• +10dBu for max output

Mic/Inst. Gain/Volume Control Range

• — to +50dB

USB Charging Port

• 5V
• 2.1A

Controls

• Power switch
• 2 gain control knobs (1 per input)
• 2 Mic/Line switches
• Bluetooth volume control encoder
• Pairing button
• Stereo Link button
• Sub Size button
• Speaker Use button

Indicators

• 1 Input Channel Signal/Limit/Clip LED (Green = Ch1/2 Signal) (Yellow = Ch1/2 Limiter) (Red = Ch1/2 Output Clipped)
• 1 Bluetooth LED (blue)
• 1 Link LED (orange)
• 4 DSP Presets LED (green)
• 3 HPF LED (green)
