AMD Radeon RX 5700

AMD Radeon RX 5700 Graphics Card

The Radeon RX 5700 is a performance-segment graphics card by AMD, launched on July 7th, 2019. Built on the 7 nm process, and based on the Navi 10 graphics processor, in its Navi 10 XL variant, the card supports DirectX 12, this ensures that all modern games will run on Radeon RX 5700. It features 2304 shading units, 144 texture mapping units, and 64 ROPs. AMD has paired 8 GB GDDR6 memory with the Radeon RX 5700, which are connected using a 256-bit memory interface. The GPU is operating at a frequency of 1625 MHz, which can be boost up to 1725 MHz, memory is running at 1750 MHz (14 Gbps effective). Being a dual-slot card, the AMD Radeon RX 5700 draws power from a combined 1x 6-pin + 1x 8-pin power connectors, with power draw rated at 180 W maximum. Display outputs include: 1x HDMI 2.0b, 3x DisplayPort 1.4a. Radeon RX 5700 is connected to the rest of the system using a PCI-Express 4.0 x16 interface.

AMD Radeon RX5700 GDDR5 256-bit Displayport / HDMI / RDNA 1 Artchitecture/ MSI Model /

Features

• FSR Support(FidelityFX Super Resolution)
• FreeSync Technology Ready
• PCI Express 4.0 x16
• VR Ready

API Supports

• OpenCL 2.1
• DirectX 12(12.1)
• Vulkan 1.3
• OpenGL 4.6

More Specifications:

• Memory Type :  GDDR6
• Available Video Memory Capacity :  8 GB
• Video Memory Speed :  1750 MHz
• Bus width:  256 bit

• Memory Bandwidth : 448.0 GB/s
• GPU Clock Speed :  1625 MHz
• GPU Boost CLock Speed :  1725 MHz
• SHading units :  2304

• Texture Mapping Units :  144
• Render Output Units(ROPs) :  64
• DisplayPort Interface Quantity:  3
• PSU Output Power Required:  +500 W
• Cooling System Type:  2 x fan Axial Design
