Amphenol (MS3102A-10SL3S) Circular Connector, 3 Contacts, Solder Socket

Circular Connector, MIL-DTL-501Product OverviewThe MS3102A-10SL3S is a 3-contact Circular Connector with silver-plated coppercontacts, solid shell and 10SL-3 insert arrangement. This box mountingreceptacle has socket type contacts and high grade aluminium alloy shell.Electrically conductive cadmium plate finish with an olive drab chromateafter-treat offers corrosion resistance. Resilient neoprene inserts provideshigh dielectric strength, high arc resistance and resistance to vibration. Thisconnector represents well-proven electrical capability at an acceptable cost formost equipment where durability is important. MIL-C-5015 features threadedcoupling, single key and keyway polarization representing maximum simplicity indesign. Suitable for ordnance and shipboard installation where mechanical forcesand physical parameters are not subject to extreme or rapid environmentalchanges.Medium to heavy weight cylindricalDurable and field-proven design3000VAC RMS at Sea level operating voltageSplit end bell service classApplicationsAerospace, Defence, Military, Communications & Networking, Computers & ComputerPeripheralsProduct InformationMilitary Specification: MIL-DTL-5015 SeriesCircular Connector Shell Style: Box Mount ReceptacleNo. of Contacts: 3ContactsCircular Contact Type: Solder SocketCoupling Style: ThreadedInsert Arrangement: 10SL-3Connector Body Material: Aluminium Alloy BodyConnector Body Plating: Olive Drab Chromate over CadmiumContact Material: Brass, Copper AlloyContact Plating: SilverInsert Rotation: NService Class: General DutyProduct Range: MIL-DTL-50155 Series, Box Mount Receptacle, 3 Contacts, SolderSocket, Threaded
