Amphenol (MS3106A-22-14S) Circular Connector, 19 Contacts, Solder Socket

Circular Connector, MIL-DTL-5015 Series, Straight Plug, 19 Contacts, SolderSocket, Threaded, 22-14Product OverviewThe MS3106A22-14S is a 19-contact Circular Connector with silver-plated copperalloy socket contacts, solid shell and 22-14 insert arrangement. Shellcomponents are fabricated from high grade aluminum alloy. Electricallyconductive cadmium plate finish with an olive drab chromate after-treat offerscorrosion resistance. Resilient neoprene inserts provides high dielectricstrength, high arc resistance and resistance to vibration. This connectorrepresents well-proven electrical capability at an acceptable cost for mostequipment where durability is important. MIL-C-5015 features threaded coupling,single key and keyway polarization representing maximum simplicity in design.Suitable for ordnance and shipboard installation where mechanical forces andphysical parameters are not subject to extreme or rapid environmental changes.Medium to heavy weight cylindricalDurable and field-proven design3000VAC RMS at Sea level operating voltageSplit end bell service classApplicationsAerospace, Defence, Military, Communications & Networking, Computers & ComputerPeripheralsProduct InformationMilitary Specification: MIL-DTL-5015 SeriesCircular Connector Shell Style: Straight PlugNo. of Contacts: 19ContactsCircular Contact Type: Solder SocketCoupling Style: ThreadedInsert Arrangement: 22-14Connector Body Material: Aluminium Alloy BodyConnector Body Plating: Olive Drab Chromate over CadmiumContact Material: Brass, Copper AlloyContact Plating: SilverInsert Rotation: NService Class: General DutyProduct Range: MIL-DTL-5015
