Analog Devices (MAX1406CPE+)Transceiver RS232, 4.5V-5.5V supply

Product OverviewThe MAX1406CPE+ is a ±15KV ESD protected, EMC compliant, 230Kbps,3-transmitter/3-receiver RS232 transceiver in 16 pin DIP package. Alltransmitter outputs and receiver inputs are protected to ±15KV using IEC1000-4-2air-gap discharge, ±8KV using IEC 1000-4-2 contact discharge and ±15KV using thehuman body model. The device is pin and functionally compatible with theindustry standard MC145406 and existing designs can instantly becomeelectromagnetic compatibility (EMC) compliant. It is optimized for operation inprinter, modem and telecom applications and also provides compatibility withpopular software for communicating with personal computers.Supply voltage range is 4.5V to 5.5VOperating temperature range from 0°C to 70°CLatchup free during an ESD eventFlow through pin-outEquipment Meeting IEC 1000-4-2; Instruments; Modems; Printers;TelecommunicationsProduct InformationDevice Type: TransceiverIC Interface Type: RS232No. of Drivers: 3DriversNo. of Receivers: 3ReceiversSupply Voltage Min: 4.5VSupply Voltage Max: 5.5VDriver Case Style: DIPNo. of Pins: 16PinsOperating Temperature Min: 0°COperating Temperature Max: 70°CProduct Range: -Automotive Qualification Standard: -MSL: MSL 1 - UnlimitedIC Generic Number: MAX1406
