******Please note unit has no mounting brackets **************
                                                                                                          ******Unit has been reset to FAT state and needs to be resetup to FIT state ************

SOLD - AS-IS - NO RETURNS

Huawei AP8150DN Product Features

• 11ac wave 2 standards compliance, MU-MIMO (2SU-2MU), delivering services simultaneously on 2.4G and 5G radios; 400 Mbit/s at 2.4 GHz; 867 Mbit/s at 5 GHz; and 1.267 Gbit/s for the device
• AP8150DN can switch from the 2.4 GHz frequency band to the 5 GHz frequency band. When working at dual 5 GHz frequency bands simultaneously, the AP provides a system rate of 1.73 Gbit/s and can function as a relay AP to implement wireless bridging functions, which reduces costs and improves device installation efficiency.
• Built-in Bluetooth, allowing for Bluetooth-based application extension.
• Built-in 5 kA surge protectors; no additional surge protection device required. This design simplifies installation and saves costs.
• Use a metal shell and heat dissipation design, adapt to a wide temperature range from -40°C to +65°C, provide 6 kA or 6 kV surge protection capability on an Ethernet interface, and IP68 protection level, meeting industry-level use requirements.
• Support the Fat, Fit, and cloud modes and enables Huawei cloud-based management platform to manage and operate APs and services on the APs, reducing network O&M costs

Huawei AP8150DN Specification

Dimensions (H x W x D): 100 mm x 220 mm x 220 mm

Power Input: PoE power supply: In compliance with IEEE 802.3 at

Maximum Power Consumption: AP8150DN: 18W

Note: The actual maximum power consumption depends on local laws and regulations

Antenna Type: AP8150DN: External antennas

Maximum Number of Concurrent Users:  512

Maximum Transmit Power

AP8150DN:

2.4G: 27 dBm (combined power)

5G: 24 dBm (combined power)

Note: The actual transmit power depends on local laws and regulations

MIMO: Spatial Streams: 2 x 2:2

Radio Protocols: 802.11a/b/g/n/ac/ac Wave 2

Maximum Rate: AP8150DN: 1.73 Gbit/s
