Apacer AS2280P4X M.2 PCIe Gen3 x 4 256GB SSD

Apacer AS2280 M.2 PCIe SSD - 256GB Capacity, PCIe Gen3 x 4 Interface, NVMe 1.3 Standard, Extremely Thin And M.2 Interface, 2100MB/s Sequential Read Performance, 1700MB/s Sequential Write Performance, Up to 530K IOPs, 0°C ~ 70°C Operating Temperature, -40°C ~ 85°C Storage Temperature, Retail Box, 3 Years Warranty.

Product Overview

Apacer AS2280P4X PCIe Gen3 x4 NVMe SSD Boost your system with 3D NAND storage delivering up to 2,100MB/s read, 1,700MB/s write, and 530K 4K random write IOPS (256GB-2TB). M.2 2280 single/double-sided (80x22x2.25/3.5mm, 6.8g) endures 1,500G shock, 0-70°C operation, and >1.5M hours MTBF. CE/FCC/RoHS certified with 3-year/TBW warrantyideal for upgrades in PCs, laptops, and devices needing reliable high-speed storage.

Features

Adopts a PCIe Gen3 x4 interface
Compliant with NVMe 1.3 standard
Extremely thin and light M.2 interface
Read and write speeds up to 2,100 / 1,700 MB/s
High-speed Performance for Everyone
Large Capacity in a Compact Space
Built-in Protection Technologies Improve Stability And Reliability

Specifications

Product Code: AS2280P4X
Description: Apacer AS2280P4X M.2 PCIe Gen3 x 4 SSD
Capacity: 256GB
Interface: PCIe Gen3 x4
NAND Flash: 3D NAND
Sequential Read Performance: Up to 2,100 MB/s
Sequential Write Performance: Up to 1,700 MB/s
IOPs (4K Random Write): Up to 530K
Shock: 1,500G/0.5msec
MTBF: >1,500,000 hours
Standard Operating Temperature: 0°C ~ 70°C
Storage Temperature: -40°C ~ 85°C
Dimensions
Single side : (L)80.00 x (W)22.00 x (H)2.25mm
Double side : (L)80.00 x (W)22.00 x (H)3.5mm
Weight: 6.8g
Certificate: CE, FCC, VCCI, BSMI, RoHS
Warranty: 3 years
