Features:
Adjustable voltage sensitivity
-Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
Adjustable voltage-transfer points
-Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
Audible alarms
-Provides notification of changing utility power and UPS power conditions
Automatic self-test
-Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Battery failure notification
-Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Boost Automatic Voltage Regulation (AVR)
-Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.
LED status indicators
-Quickly understand unit and power status with visual indicators.
Resettable circuit breaker
-Easy recovery from overloads; no need to replace a fuse.
Safety-agency approved
-Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
Benefits:
Availability
Intelligent battery management
-Maximizes battery performance, life, and reliability through intelligent, precision charging.
Battery failure notification
-Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Automatic self-test
-Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Marketing Features
Battery-protected and surge-only outlets
-Reserves power capacity and run time for connected equipment that require UPS battery back-up while providing surge only protection for less critical equipment
Protection
Battery and surge protected outlets
-Back up and protect your hardware and data during power outages, surges and spikes.
Surge only outlets
-Protect secondary electronics from surges and spikes without reducing battery power used to run primary electronics during an outage.
Safety
Safety-agency approved
-Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
Manageability
Audible alarms
-Provides notification of changing utility power and UPS power conditions
LED status display
-Quickly understand unit and power status with visual indicators.
Specifications:
Output
-Output power capacity: 300Watts / 500VA
-Max Configurable Power (Watts): 300Watts / 500VA
-Nominal Output Voltage: 230V
-Output Frequency (sync to mains): 50 Hz
-Output Frequency (not synced): 50Hz +/- 0.1% for 50Hz nominal
-Topology: Line Interactive
-Waveform type: Stepped approximation to a sinewave
-
Output Connections:
-(1) IEC Jumpers (Battery Backup)
-(3) IEC 320 C13 (Battery Backup)
-Transfer Time: 6ms typical : 10ms maximum
Input
-Nominal Input Voltage: 230V
-Input frequency: 45 - 65 Hz
-Input Connections: IEC-320 C14
-Cord Length: 1.83meters
-Input voltage range for main operations: 160 - 280V
-Number of Power Cords: 1
-Maximum Input Current: 2.0A
Communications & Management
-Control panel: LED status display with On Line : On Battery : Replace Battery and Overload indicators
-Audible Alarm: Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering
-Surge energy rating: 273Joules
Physical
-Maximum Height: 185mm , 18.5cm
-Maximum Width: 115mm , 11.5cm
-Maximum Depth: 213mm , 21.3cm
-Net Weight: 5.2kg
-Shipping weight: 5.68kg
-Shipping Height: 257mm , 25.7cm
-Shipping Width: 190mm , 19.0cm
-Shipping Depth: 291mm , 29.1cm
-Color: Black
-Master Carton Units: 2.0
-Units per Pallet: 60.0
-SCC Codes: 6073130430736 7
Environmental
-Operating Environment: 0 - 40 °C
-Operating Relative Humidity: 0 - 95 %
-Operating Elevation: 0-3000meters
-Storage Temperature: -15 - 45 °C
-Storage Relative Humidity: 0 - 95 %
-Storage Elevation: 0-15000meters
-Audible noise at 1 meter from surface of unit: 45.0dBA
1 Year Warranty
