APC Smart-UPS SRT 3000VA 230V
Features
- This product is part of the Smart-UPS On-Line range that provides high density, true double-conversion on-line power protection.
- This 3000VA/2700W On-line pure sine wave UPS provides scalable runtime while minimizing maintenance.
- The 2U rack/tower convertible SRT is external battery compatible for more runtime during prolonged outages.
- The UPS has an optional Network Management Card for network-based monitoring and PowerChute Business Edition for unattended shutdown.
- It comes with BS1363A British, IEC 60320 C20, and Schuko CEE 7/EU1-16P inputs, 8x IEC 320 C13/60320 C13 and 2x IEC 320 C19/60320 C19 outlets, and 2x IEC jumpers. Ideal for servers, voice/data networks, medical labs, and light industrial applications.
- It conforms to CE, CE Mark, EAC, EN/IEC 62040-1, EN/IEC 62040-2, RCM, and VDE.
- Designed for IT professionals or network administrators providing wide input voltage window, tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.
Technical Specification
Main
Main Input Voltage: 230 V
Main Output Voltage: 230 V
Rated power in W: 2700 W
Rated power in VA: 3000 VA
Input Connection Type
- BS1363A British
- IEC 60320 C20
- Schuko CEE 7 / EU1-16P
Output connection type
- 8x IEC 60320 C13
- 2x IEC Jumpers
- 2x IEC 60320 C19
Cable length: 2.44 m
Number of cables: 3
Batteries & Runtime
Battery type: Lead-acid battery
Battery recharge time: 3 h
Number of battery replacement quantity: 1
Battery voltage: 96 V
Battery charger power: 168 W rated
General
UPS type: Double conversion online
Product web sub-family: High density
Redundant: No
Physical
Product colour: Black
Dimension (H x W x D): 43.2 x 8.5 x 63.5 cm
Net weight: 31.3 kg
Mounting location: Front
Mounting preference: Lower
Mounting mode: Rack-mounted with kit
USB compatible: Yes
Mounting position: Vertical
Input
Network frequency: 40...70 Hz auto-sensing
Input voltage limits: 100...275 V adjustable (half load)
Output
Maximum configurable power in VA: 3000 VA
Maximum configurable power in W: 2700 W
Output frequency: 50/60 Hz +/- 3 Hz sync to mains
Wave type: Sine wave
Harmonic distortion: Less than 2 %
Crest factor: 3 : 1
Bypass type: Internal bypass (automatic and manual)
Communications & Management
Free slots: 1
Alarm: Audible and visible alarms : prioritized by severity
Emergency power off: Yes
Surge Protection and Filtering
Surge energy rate: 340 J
Package contents
- CD with software
- Country-specific detachable power cord
- Documentation CD
- Installation guide
- Removable support feet
- USB cable
- Warranty card
