Arcol (ACS10S47RJ) Through Hole Resistor, Silicone Coated, 47 ohm

Through Hole Resistor, Silicone Coated, 47 ohm, ACS, 10 W, ± 5%, Axial Leaded,700 VProduct InformationResistance: 47ohmProduct Range: ACSPower Rating: 10WResistance Tolerance: ± 5%Resistor Case / Package: Axial LeadedVoltage Rating: 700VResistor Element Type: WirewoundTemperature Coefficient: ± 20ppm/°CAutomotive Qualification Standard: -Product OverviewThe ACS10S series from Arcol/Ohmite are silicone coated axial leaded resistors.Design of the ACS resistor provides a good balance of power density, stabilityand resistance to environment for a broad range of industrial power applicationssuch as drives and controls. Resistance range include E24 and E12 decade values(for values >10K).Inductive resistance range of 0.1ohm to 30Kohm & non inductive resistance rangeof 0.1ohm to 5KohmBody diameter is 8.52mm (±0.8) and 1mm (±0.02) drill hole35mm (±1) lead length and 44.2mm (±1.5) body lengthOperating temperature range from -55°C to 350°CGood ratio between power capability and physical sizeWound to maximise high pulse capability, low inductive versions availableTemperature coefficient of resistance wire is ±20ppmAvailable with ±1%, ±5% tolerance valuesInsulation resistance of 1000Mohm (> 100V) and dielectric withstand voltage is500VContinuous working voltage is 700V and rated power is 10WHigh Power Resistor
