Operating Voltage: 5V
Input Voltage (Recommended): 7-12V
Power 5V: Provided through USB Type-B Port
Power External: Through 2.1mm barrel jack (7v to 12v DC)
Digital I/O Pins: 14 (of which 6 provide PWM output)
Digital I/O: 3.3v Logic Levels
PWM Digital I/O Pins: 6
Analog Input Pins: 6 (3.3v Logic Levels)
ISP Programming: Available through TX/RX ports
DC Current per I/O Pin: 20 mA
DC Current for 3.3V Pin: 50 mA
Flash Memory: 32 KB
SRAM: 2 KB
EEPROM: 1KB
Clock Speed: 16 Mhz Oscillator
The Arduino Uno R3 from Wavgat has a set of drivers which ensures compatibility. We have created a for reference which includes links to the Arduino IDE (Integrated Development Environment) along with drivers.
SEE FOLLOWING LINK FOR SETUP INSTRUCTIONS
https://www.pcboard.ca/arduino-uno-r3-wavgat-setup
