Exclusive EZ mode adds useful info to become even easier
Media-renowned UEFI BIOS from ASUS provides the smooth mouse-controlled graphical BIOS, and now features more intuitive functions to quickly take you to favorite BIOS pages and frequently-accessed settings through custom shortcuts. You can even write quick notes in-BIOS for future reference, view an activity log of setting changes and modifications, and rename SATA ports.
USB 3.0 Boost (UASP support)
ASUS USB 3.0 Boost technology supports UASP (USB Attached SCSI Protocol). With USB 3.0 Boost technology, a USB device's transmission speed is significantly increased up to 170%, adding to already fast USB 3.0 performance. ASUS software automatically accelerates data rates for compatible USB 3.0 peripherals without any user interaction.
Effortless PCI Express component removal
Press the Q-slot clip lightly, and graphics cards just pop out. The large winged clip is easy to reach so you don't have to struggle with installing or removing even the biggest graphics cards.
Intel H81 Express chipset
The Intel H81 Express chipset is a single-chipset design that supports socket LGA1150 4th generation Intel Core i7/i5/i3/Pentium/Celeron processors. It provides improved performance by utilizing serial point-to-point links, allowing increased bandwidth and stability. It natively supports up to two USB 3.0 ports for up to ten times faster transfer rates than USB 2.0. Moreover, the Intel H81 Express chipset also supports iGPU functionality, letting users enjoy the Intel integrated graphics performance.
GreenASUS
Motherboards are EU Energy-related Products (ErP) ready, which requires products meet high efficiency standards with regards to energy consumption. This is in line with the ASUS vision of creating environmentally-friendly and energy-efficient products through design and innovation that reduce the carbon footprint of products and thus mitigate ecological impact.
Specifications
General
Product Type Motherboard - micro ATX
Processor: Core i5 4th gens
Chipset Type Intel H81 Express
Processor Socket LGA1150 Socket
Max Processors Qty 1
Compatible Processors Pentium, Celeron, Core i5, Core i3, Core i7
Supported RAM
Max Size 16 GB
Ram not included
Technology DDR3
Bus Clock 1600 MHz, 1333 MHz, 1066 MHz
Supported RAM Integrity Check Non-ECC
Registered or Buffered Unbuffered
Features Dual channel memory architecture
Graphics
Max Allocated RAM Size 1024 MB
Audio
Type HD Audio (8-channel)
Audio Codec Realtek ALC887
Compliant Standards High Definition Audio
LAN
Network Controller Realtek RTL8111G
Network Interfaces Gigabit Ethernet
Expansion / Connectivity
Expansion Slots 1 x CPU ¦ 2 x DIMM 240-pin ¦ 1 x PCIe 2.0 x16 ¦ 2 x PCIe 2.0 x1 ¦ 1 x PCI
Storage Interfaces SATA-300 -connectors: 2 x 7pin Serial ATA - 2 devices ¦ SATA-600 -connectors: 2 x 7pin Serial ATA - 2 devices
Interfaces 1 x DVI ¦ 2 x USB 3.0 ¦ 1 x VGA ¦ 1 x LAN (Gigabit Ethernet) ¦ 4 x USB 2.0 ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x PS/2 keyboard ¦ 1 x PS/2 mouse ¦ 1 x parallel
Internal Interfaces 4 x USB 2.0 - header ¦ 1 x serial - header ¦ 1 x audio - header
Power Connectors 4-pin ATX12V connector, 24-pin main power connector
Features
BIOS Features DMI 2.0 support, WfM 2.0 support, ASUS MyLogo2, ASUS Quiet Thermal Solution, ASUS EZ Flash 2, ACPI 2.0a support, ASUS EFI BIOS, SMBIOS 2.7 support
Sleep / Wake Up Wake on LAN (WOL)
Hardware Features ASUS Anti-Surge Protection, ESD Guards, GPU Boost, ASUS EZ DIY, Q-Slot, CrashFree BIOS 3, All-Solid Capacitor motherboard Design, ASUS EPU (Energy Processing Unit), ASUS Fan Xpert, Intel Turbo Boost Technology 2.0, ASUS USB 3.0 Boost technology, ASUS Network iControl, ESD Protection, ASUS Stainless Steel Back I/O
Packaging:
Included Accessories I/O back plate
Included Heat sink
Width 24.4 cm
Depth 17.8 cm
