| CPU | Intel® Socket 1156 Core™ i7 Processor/Core™ i5 Processor Supports Intel® Turbo Boost Technology * Refer to www.asus.com for Intel CPU support list |
| Chipset | Intel® P55 Express Chipset |
| Memory | 4 x DIMM, Max. 16 GB, DDR3 2133(O.C.)*/2000(O.C.)/1600/1333/1066 Non-ECC,Un-buffered Memory Dual Channel memory architecture * Hyper DIMM support is subject to the physical characteristics of individual CPUs. **Supports Intel® Extreme Memory Profile (XMP) *** Please refer to www.asus.com or user manual for the Memory QVL(Qualified Vendors Lists). |
| Expansion Slots | 2 x PCIe 2.0 x16 (support single at x16 or dual at x8/x8 mode) 1 x PCIe x4 1 x PCI 2.2 |
| Multi-GPU Support | Supports NVIDIA® Quad-GPU SLI™ Technology / ATI® Quad-GPU CrossFireX™ Technology |
| Storage | Intel® P55 Express Chipset built-in 6 xSATA 3.0 Gb/s ports Intel Matrix Storage Technology Support RAID 0,1,5,10 JMicron® JMB363 SATA controller 1 xExternal SATA 3.0 Gb/s port at rear (SATA On-the-Go) 1 xSATA 3.0 Gb/s port |
| LAN | Gigabit LAN controller featuring AI NET2 GameFirst |
| Audio | SupremeFX X-Fi built-in - 8-channel High Definition Audio CODEC - EAX® Advanced™ HD 4.0 - X-Fi CMSS®-3D - X-Fi Crystalizer™ - Creative ALchemy - Blu-ray support - Supports Optical S/PDIF out port on rear |
| IEEE 1394 | 2 x 1394a ports (1 port at back I/O, 1 port onboard) |
| USB | 14 USB 2.0/1.1 ports (5 ports at mid-board, 9 ports at back panel) |
| ASUS Unique Features | MemOK! MemPerfect ProbeIt Onboard Switches: Power / Reset / Clr CMOS (at rear) ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) ASUS Q-Connector ASUS Q-Slot ASUS Q-DIMM ASUS EPU ASUS Fan Xpert ASUS MyLogo3 ASUS EZ Flash 2 ASUS CrashFree BIOS 3 |
| Overclocking Features | CPU Power Design - 8-phase CPU power - 2-phase VTT power - 2-phase Memory power ROG Connect CPU Level Up iROG Extreme Tweaker Loadline Calibration Intelligent overclocking tools: - ASUS TurboV EVO - O.C. Profile Overclocking Protection: - COP EX (Component Overheat Protection - EX) - Voltiminder LED - ASUS C.P.R.(CPU Parameter Recall) |
| Back Panel I/O Ports | 1 x External SATA 1 x S/PDIF Out (Optical) 1 x IEEE 1394a 1 x LAN(RJ45) port 9 x USB 2.0/1.1 1 x PS/2 Keyboard port (purple) 1 x Clr CMOS switch 1 x ROG Connect On/Off switch 8-channel Audio I/O with gold-plated jack |
| Internal I/O Connectors | 3 x USB connectors supports additional 5 USB 2.0 ports (1 port reserved for ROG Connect at rear) 1 x IEEE 1394a connector 7 x SATA connectors (one is from JMicron® 363 (black)) 5 x Fan connectors: 1 x CPU / 2 x Chassis / 2 x Optional 1 x SPDIF out header 1 x CD audio in 1 x Front panel audio connector 2 x thermal sensor connectors 1 x 24-pin ATX Power connector 1 x 8-pin ATX 12V Power connector 1 x En/Dis-able Clr CMOS header 5 x ProbeIt measurement points 1 x Go Button System panel connector |
| BIOS | 16 Mb Flash ROM , AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.4, ACPI2.0a Multi-Language BIOS |
| Manageability | WOL by PME,WOR by PME,PXE |
| Accessories | User's manual 1 x I/O Shield 1 x ROG Connect Cable 1 x ROG Cable Labels (12 in 1) 1 x SLI Cable 1 x 2-in-1 ASUS Q-Connector Kit 3 x 2-in-1 SATA signal cables 1 x Cable Ties 1 x ROG Theme Label |
| Support Disc | Support DVD: - Drivers and applications Sound Blaster X-Fi Utility ROG GameFirst Utility ASUS TurboV EVO Utility ASUS PC Probe II ASUS Update ASUS AI Suite Kaspersky® Anti-Virus |
| Form Factor | uATX Form Factor 9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm ) |
