CPU | Intel® Socket 775 Core™2 Quad/Core™2 Extreme/Core™2 Duo/Pentium® D/Pentium® 4/Celeron® E1000 Series and Celeron 400 Series Processors Support Intel next generation 45nm CPU Intel® Hyper-Threading Technology ready Supports Enhanced Intel SpeedStep® Technology(EIST) |
Chipset | Intel® G31 / ICH9R /ICH7 |
Front Side Bus | 1600(O.C)/1333/1066/800/533 MHz |
Memory | 2 x DIMM, Max. 4 GB, DDR2 1066(O.C.)/800/667 Non-ECC,Un-buffered Memory Dual Channel memory architecture Please refer to www.asus.com or user manual for Memory QVL. |
Expansion Slots | 1 x PCIe x16 1 x PCIe x1 1 x PCI |
VGA | Integrated Intel Graphics Media Accelerator (Intel® GMA 3100) Max. resolution:2048x1536X32bpp, Horizontal:127.5KHz Vertical:85Hz |
Storage | Southbridge 1 xUltraDMA 100/66/33 2 xSATA 3 Gb/s ports |
LAN | RTL8102EL 10/100M |
Audio | ALC662 6-Channel High-Definition Audio CODEC |
USB | 8 USB 2.0 ports (4 ports at mid-board, 4 ports at back panel) |
ASUS AI Lifestyle Features | ASUS Quiet Thermal Solution: - ASUS Q-Fan ASUS EZ DIY: - ASUS CrashFree BIOS 3 - ASUS EZ Flash 2 Other Feature: - ASUS MyLogo 2 |
Back Panel I/O Ports | 1 x VGA 1 x PS/2 Keyboard 1 x PS/2 Mouse 1 x LAN(RJ45) port 4 x USB 2.0/1.1 1 x COM port 6 -Channel Audio I/O |
Internal I/O Connectors | 1 x High Definition front panel audio connector 1 x IDE connector 1 x CD audio-in connector 1 x CPU fan connector 1 x Chassis fan connector 2 x SATA connectors 2 x USB 2.0 connectors for 4 additional USB 2.0 ports 1 x 24-pin EATX power connector 1 x 4-pin x ATX 12V power connector 1 x System panel connector |
BIOS | 8 Mb Flash ROM AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5 |
Manageability | WOL,PXE,RPL,WOR ,PME Wake Up |
Accessories | 1 x SATA cable 1 x Ultra ATA66 cable I/O Shield User's manual |
Support Disc | Drivers ASUS PC Probe II ASUS Update |
Form Factor | uATX Form Factor 9.6 inch x 7.2 inch ( 24.5 cm x 18.3 cm ) |
