ASUS P8Z77-M PRO - INTEL Z77 CHIPSET - LGA 1155 FOR INTEL 3RD/2ND GENERATION CORE I7/CORE I5 AND CORE I3 PROCESSORS - SUPPORTS INTEL TURBO BOOST TECHNOLOGY 2.0 - MATX FORM FACTOR, 4X DDR3 (MAX 32GB), INTEGRATED GRAPHICS PROCESSOR WITH MULTI-VGA OUTPUT SUPPORT, 2 X PCIE 3.0/2.0 X16 (X16 OR DUAL X8), 1 X PCIE 2.0 X16 (X4 MODE, BLACK), 1 X PCIE 2.0 X1, 1 X PCI, 2X SATA 6GB/S, 4X SATA 3GB/S (RAID 0,1,5,10), 4X USB 3.0, 10X USB 2.0, 10/100/1000GB LAN, ALC 892 8-CHANNEL HIGH DEFINITION AUDIO CODEC, BACK PANEL: 1X PS2 KEYBOARD/MOUSE COMBO PORTS, 1X DVI, 1X D-SUB, 1X HDMI, 2X ESATA 6GB/S, 1X LAN (RJ45), 2X USB 3.0, 4X USB 2.0, 1X OPTICAL S/PDIF OUT, 6X AUDIO JACKS. Retail Box 3 year warranty
Specifications
CPU Supported
Intel® Socket 1155 for 3rd/2nd Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors
Supports Intel® 22 nm CPU
Supports Intel® 32 nm CPU
Supports Intel® Turbo Boost Technology 2.0
Chipset:Intel® Z77
Memory Supported
4 x DIMM DDR3 1600/1333 MHz Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Graphic
Integrated Graphics Processor
Multi-VGA output support : HDMI/DVI/RGB ports
- Supports HDMI with max. resolution 1920 x 1200 @ 60 Hz
- Supports DVI with max. resolution 1920 x 1200 @ 60 Hz
- Supports RGB with max. resolution 2048 x 1536 @ 75 Hz
Maximum shared memory of 1696 MB
Supports NVIDIA® Quad-GPU SLI™ Technology *1
Supports AMD Quad-GPU CrossFireX™ Technology
Supports AMD 3-Way CrossFireX™ Technology
Expansion Slots
2 x PCIe 3.0/2.0 x16 (x16 or dual x8) *3
1 x PCIe 2.0 x16 (x4 mode, black)
1 x PCIe 2.0 x1
Storage
2 x SATA 6Gb/s port(s), gray
4 x SATA 3Gb/s port(s), blue
Support Raid 0, 1, 5, 10
ASMedia® ASM1061 controller : *5
2 x eSATA 6Gb/s port(s), red
LAN:Realtek® 8111F, 1 x Gigabit LAN Controller(s)
Audio
Realtek® ALC892 8-Channel High Definition Audio CODEC
- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Absolute Pitch 192kHz/ 24-bit True BD Lossless Sound
- Optical S/PDIF out port(s) at back panel
Back I/O Ports
1 x PS/2 keyboard/mouse combo port(s)
1 x DVI-D
1 x D-Sub
1 x HDMI
2 x eSATA 6Gb/s
1 x LAN (RJ45) port(s)
4 x USB 3.0
2 x USB 2.0
1 x Optical S/PDIF out
6 x Audio jack(s)
Internal I/O Ports
1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) (19-pin)
3 x USB 2.0 connector(s) support(s) additional 6 USB 2.0 port(s)
1 x TPM connector(s)
1 x COM port(s) connector(s)
2 x SATA 6Gb/s connector(s)
4 x SATA 3Gb/s connector(s)
1 x CPU Fan connector(s) (4 -pin)
3 x Chassis Fan connector(s) (4 -pin)
1 x S/PDIF out header(s)
1 x 24-pin EATX Power connector(s)
1 x 8-pin ATX 12V Power connector(s)
1 x Front panel audio connector(s) (AAFP)
1 x System panel(s) (Q-Connector)
1 x TPU switch(es)
1 x EPU switch(es)
1 x USB BIOS Flashback button(s)
Form Factor
uATX Form Factor
9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )
