Aten CL5708M 17-inch 8-port TFT-LCD VGA KVM Switch

Aten CL5708M 17-inch 8-port TFT-LCD VGA KVM Switch

The Aten CL5708 8 port 17 Slideaway Combo KVM switch is Dual Interface supports computers and console with PS/2 or USB keyboards and mice, Multiplatform support Windows, Linux, Mac, and Sun, and Supports one administrator and four user accounts with separate profiles. The LCD module rotates up to 115 degrees for a more comfortable viewing angle and has Two level password security only authorized users can view and control computers.

The Aten CL5708M Slideaway 17 LCD KVM Switch is a control unit that allows access to multiple computers from a single PS/2 or USB KVM (keyboard, video, and mouse) console. A single CL5708 can control up to 8 computers. As many as 31 additional KVM switches can be daisy-chained to the CL5708M, so that up to 256 computers can all be controlled from a single KVM console.

The CL5708M offers a space-saving, streamlined approach to KVM switch technology by integrating a keyboard, 17 or 19 LED-backlit LCD monitor, and touchpad in a 1U rack-mountable sliding housing.

Features:

• Exclusive LED illumination light designed by ATEN to illuminate the keyboard and touchpad to allow visibility in low-light conditions
• Integrated KVM console with 17 or 19 LED-backlit LCD monitor in a Slideaway housing
• Available with or without Fingerprint Identification Reader**
• Space saving technology up to two consoles (one bus) control up to 8 computers
• Daisy-chain up to 31 additional units control up to 256 computers from a single console (With compatible KVM Switches: ACS1208A, ACS1216A, CS1708A,CS1716A)
• Dual Interface supports computers and console with PS/2 or USB keyboards and mice
• LCD module USB port allows each computer to access USB peripherals*

Specifications:

• LCD module rotates up to 115 degrees for a more comfortable viewing angle
• Multiplatform support: Windows, Linux, Mac, and Sun
• Supports multimedia USB keyboards for PC, Mac and Sun
• Auto PS/2 and USB interface detection
• Keyboard and mouse emulation (PS/2 and USB) for smooth switching and simultaneous booting of multiple computers even when the console focus is elsewhere
• Supports external USB mouse
• Superior video quality: supports resolutions up to 1280 x 1024 @ 75 Hz
• No software required: convenient computer selection via front panel pushbuttons, hotkeys and multilingual on-screen display (OSD) menus
• Auto-senses station's position on daisy-chained installations; no need for manual dip switch setting; front panel led indicates station's position
• Port names automatically reconfigured when station sequence is changed
• Two level password security: only authorized users can view and control computers
• Supports one administrator and four user accounts with separate profiles
• Auto Scan mode enables continuous monitoring of user-selected computers
• Broadcast support: commands from the keyboard can be broadcast to all available computers on the installation
• Hot pluggable: add or remove computers without having to power down the switch
• Beeper on/off via hotkey and OSD
• Firmware upgrades to all the chained KVM switches at the same time via the daisy-chain cable
• Keyboard Language support: English (US), English (UK), French, German, German (Swiss), Greek, Hungarian, Italian, Japanese, Korean, Russian, Spanish, Swedish and Traditional Chinese* The USB peripheral function only works with USB cable set connections. It will not work with PS/2 cable set connections.
