Features:
￣ﾀﾐNew Eye Protection Design￣ﾀﾑThe laser protective cover perfectly protect your eyes, filter UV light for 97%. You can watch laser engraving without wearing goggles.
￣ﾀﾐNew Laser with Knob￣ﾀﾑIt is more convenient and quick to adjust the height of the laser.
￣ﾀﾐSolid and Quick Assembly Structure Design￣ﾀﾑThe full-metal structure design makes the machine more solid, and improves the accuracy of engraving. The entire structure has been designed for quick assembly within 10-20 minutes.
￣ﾀﾐPrecise Scale Lines Axis￣ﾀﾑThere are precise scale lines on the X-axis and Y-axis to facilitate quick length measurement. 410x400mm large area engraving interval can meet your various engraving needs.
￣ﾀﾐIntegrated Stepper Motor and Shaft￣ﾀﾑThe machine uses an integral screw rod instead of a combined coupling. The stepping motor and the screw rod are integrated, which makes the laser movement more precise and the coupling more durable.
￣ﾀﾐUpgraded High-Performance Fixed-Focus Laser￣ﾀﾑUpgraded high-performance fixed-focus laser: no need to adjust the focus before engraving; the new laser focal spot ￂﾠis 50% smaller than other ordinary lasers, Compared with ATOM STACK A5 20W laser, the laser power of up to 5.5W.
￣ﾀﾐWide Compatibility￣ﾀﾑThe machine can be compatible with various mature engraving software, such as LaserGRBL, LightBurn, support Win XP / Win 7 / Win 8 / XP / Win 10, and also support MAC system (LightBurn), engraving file format supports NC, BMP, JPG, PNG, DXF etc.
Specification:
Main Material: Aluminum Alloy, Metal
Print Size: Recommend Print Size 410*400mm
Laser Power: 30w
Laser Output Power:ￂﾠ5W-5.5W
Wave Length: 445ￂﾱ5nm
Engraving Accuracy: 0.01mm
Operating Software: Lasergrbl, Lightburn, Support Win XPￂﾠ/Win 7/Win 8/Xp/Win 10 System
Input Format: NC, BMP, IPG, PNG, DXF, etc.
Data Transmission Method: Usb Connection
Input Voltage: AC100-240V, 50/60HZￂﾠ
Output Voltage: DC12V, 5A
Equipment Net Weight: 4.0kg
Equipment Size: 570*600*270mm
Packing Size: 59x35x3cm/23.2x13.7x1.1in
Package Weight: 5.6kg/12.3lb
Note:
ￂﾷ When operating the laser engraving machine, please install the laser protective cover. If it is not installed, you need to wear goggles.
ￂﾷ Please do not touch the laser emitter with your hand, or it may burn your hand.
ￂﾷ Please avoid strong impact on the machine.
ￂﾷ Children under 14 are not allowed to use this product and children over 14 need adult supervision.
ￂﾷ The light engraving machine can not be directly applied to any mirror reflecting object, which may cause injury to the operator or burn the laser.
Packing List:
1 x X-axis Assembly
2 x Section 57CM
2 x Section 48CM
1 x Control Box
3 x Support Legs
1 x Goggles
1 x Laser
1 x 24V 2A Power Adapter
1 x Power Switch Line
1 x USB Cable
Step 1~5 Installation Package
1 x M5 Wrench
10 x Rolled Belt
3 x Small Wood
1 x Focal Length Film
1 x M3 Wwrench
1 x Marker
1 x Brush
3 x small Acrylic
1 x Stainless Steel Backing Plate for Cutting
