Audio-Technica ATLK-EXT165 LINK Extender

Audio-Technica ATLK-EXT165 LINK Extender

Overview:

Allows cable-run extension of discussion/conference systems and mixers equipped with Audio-Technica LINK RJ-45 ports
With ATUC-50 Digital Discussion System, supports use of up to 100 discussion units per control unit
Supplies DC +48V power to connected devices, enabling extended cable runs
LED indicators for power on/off, power supply status, current-overload detection
Power overload protection: unit cuts power when drawn current is greater than 2.6A
Includes AT8649 table mount kit and power cable

Features:

The ATLK-EXT165 link extender allows users to extend the cable runs in compatible discussion and conference systems and mixers equipped with Audio-Technica LINK ports. When used with the ATUC-50 Digital Discussion System, it enables an increased discussion unit count of up to 100 DUs per ATUC-50CU control unit . The extender is equipped with two RJ-45 Audio-Technica LINK ports through which it supplies DC +48V power to connected devices. It can be set to power on/off automatically in tandem with a connected control unit or to operate locally, powering on/off with the press of the extender's Mode switch. The front of the unit is equipped with LED indicators that display power on/off of the extender and status of power supplied to connected devices. Another LED will blink, and the extender will stop supplying power, if a current overload (above 2.6A) is detected at the LINK ports. The ATLK-EXT165 comes with the AT8649 table mount kit that allow the extender to be mounted to the underside of a table.

Specifications:

Discussion Unit
Connections Outputs: LINK power status
Chain: DU port A/B
Power Supply AC 100V-240V 50/60Hz
Power Consumption 15W-160W (MAX)
Operating Temperature Range 0-40
Operating Humidity 25-85%
Dimensions 217mm x 326mm x 41mm
Weight 2.2kg
Accessories Included AC power cord, Quick Setup Guide, Euroblock connector (1pcs), Table mount kit, Warranty Sheet
