The MULTI XS 3600 is a versatile battery charger in a compact format that makes it convenient and easy to charge and maintain all household vehicles. The special cold mode means that you can also charge during cold winter days without problems. The MULTI XS 3600 satisfies all the home’s charging needs as it charges all types of 12V batteries.
For more info visit : http://www.ctek.com/EN-GB/MULTI-XS-3600.aspx
| MODEL | MULTI XS 3600 |
|---|---|
| Input voltage AC | 220-240VAC, 50-60Hz |
| Output voltage | Nominal: 12V |
| Efficiency | 85% |
| Charging voltage | 14.4V/0.8A, 14.4V/3.6A, 14.7V/3.6A |
| Charging current | 3.6A |
| Back current drain* | 1.3mA |
| Ripple** | 50mV rms, 0.13A |
| Ambient temperature | -20°C to +50°C, output power is reduced automatically at higher temperatures. |
| Type of charger | Four step, fully automatic switch mode with pulse maintenance. |
| Type of batteries | 12V lead-acid batteries (Wet, MF, AGM, Calcium/Calcium and GEL) |
| Battery capacity | 1.2 -120Ah |
| Dimensions (L x W x H) | 165x61x38mm |
| Insulation | IP 65 (splash and dust proof), outdoor use |
| Weight | 0.5kg |
*) Back current drain is what drains the battery if the charger is connected without the power cord connected. The MULTI XS 3600's extremely low back current drain corresponds to 1Ah per month. Many other chargers have 1Ah per day.
**) Ripple denotes the amount of interference there is to the current and voltage. A high current ripple heats the battery and shortens its life. A linear charger has a current ripple of 70 - 400% which is much larger than the maximum 5% for a modern sealed battery. Voltage ripple could harm other equipment, which is connected to the battery. The MULTI XS 3600's ripple is only 2%. The battery gains a long service life and there is no risk of damage to other electronic devices connected to the battery.
