Biostar Hi-Fi H81S2 Socket 1150

Chipset Intel H81
CPU SUPPORT  Intel® Core™ i7 LGA 1150 Processor
Intel® Core™ i5 LGA 1150 Processor
Intel® Core™ i3 LGA 1150 Processor
Intel® Pentium® LGA 1150 Processor
Maximum CPU TDP (Thermal Design Power) : 95Watt

MEMORY  Support Dual Channel DDR3 1600/1333/1066 MHz
2 x DDR3 DIMM Memory Slot
Max. Supports up to 16GB Memory

EXPANSION SLOT  1 x PCI-E x16 2.0 Slot
5 x PCI-E x1 2.0 Slot

STORAGE  2 x SATA3 Connector
2 x SATA2 Connector

USB  2 x USB 3.0 Port
2 x USB 2.0 Port
2 x USB 2.0 Header

LAN  Realtek RTL8111G - 10/100/1000 Controller

INTEGRATED VIDEO  By CPU model
Supports DX11.1
Supports HDCP

CODEC  Realtek ALC892 8-Channel Blu-ray Audio

REAR I/O  1 x PS/2 Mouse
1 x PS/2 Keyboard
2 x USB 3.0 Port
2 x USB 2.0 Port
1 x DVI Connector
1 x VGA Port
1 x RJ-45 Port
3 x Audio Connector

INTERNAL I/O  1 x Printer Header
2 x USB 2.0 Header
2 x SATA3 6Gb/s Connector
2 x SATA2 3Gb/s Connector
1 x Front Audio Header
1 x Front Panel Header
1 x S/PDIF-Out Header
1 x CPU Fan Header
2 x System Fan Header
1 x Serial Header
1 x CIR Header

H/W MONITORING  CPU / System Temperature Monitoring
CPU / System Fan Monitoring
Smart / Manual CPU Fan Control
System Voltage Monitoring

DIMENSION  ATX Form Factor Dimension: 29.5cm x 21cm ( W x L )

OS SUPPORT  Support Windows 7 / 8 / 8.1 / 10(x64)

BUNDLE SOFTWARE  BIO-Remote2
BIO-Remote
Smart Speed LAN

ACCESSORIES  2 x SATA Cable
1 x I/O Shield
1 x DVD Driver
1 x User Manual

FEATURES  Windows 8 Ready
Supports PURO Hi-Fi
Supports 100% Solid capacitor
Supports Charger Booster
Supports BIOS Online Update
