Biostar Motherboard (Clearance Sale)

Chipset

Intel H61

CPU SUPPORT

Intel® Core™ i7 LGA 1155 Processor
Intel® Core™ i5 LGA 1155 Processor
Intel® Core™ i3 LGA 1155 Processor
Intel® Pentium® LGA 1155 Processor
Maximum CPU TDP (Thermal Design Power) : 95Watt

MEMORY

Support Dual Channel DDR3 1066/1333/1600 MHz
2 x DDR3 DIMM Memory Slot
Max. Supports up to 16GB Memory

EXPANSION SLOT

1 x PCI-E x16 3.0 Slot (supported by Core i5 -3xxx / Core i7 3xxx CPU)
1 x PCI-E x1 2.0 Slot

STORAGE

4 x SATA2 Connector

USB

4 x USB 2.0 Port
2 x USB 2.0 Header

LAN

Atheros AR8152 - 10/100 Controller

INTEGRATED VIDEO

By CPU model

CODEC

VIA VT1708S 6-Channel HD Audio

REAR I/O

1 x PS/2 Mouse
1 x PS/2 Keyboard
4 x USB 2.0 Port
1 x VGA Port
1 x RJ-45 Port
3 x Audio Connector

INTERNAL I/O

2 x USB 2.0 Header
4 x SATA2 3Gb/s Connector
1 x Front Audio Header
1 x Front Panel Header
1 x CPU Fan Header
1 x System Fan Header
1 x Serial Header

H/W MONITORING

CPU / System Temperature Monitoring
CPU / System Fan Monitoring
Smart / Manual CPU Fan Control
System Voltage Monitoring

DIMENSION

Micro ATX Form Factor Dimension: 22.6cm x 17cm ( W x L )

OS SUPPORT

Support Windows XP / Vista / 7 / 8

BUNDLE SOFTWARE

BIO-Remote2

ACCESSORIES

2 x SATA Cable
1 x I/O Shield
1 x CD Driver
1 x Quick Guide

FEATURES

Windows 8 Ready
Supports Solid capacitor
Supports BIOS-Flasher
Supports Charger Booster
Supports BIOS Online Update
