PRODUCT DESCRIPTION
100% Solid Caps
With armor-plated Biostar Technology, all capacitors are placed with 100% solid capacitors that have a lasting life cycle, durability and stability for crucial components.
ESD Protection
ESD (Electrostatic Discharge) is the major factor to destroy PC by electrical overstress (EOS) condition, ESD occurred when PC users touch any devices connected to the PC, which may result in damage to motherboard or parts. ESD protection is designed to protect the motherboard and equipment from damage by EOS.
USB Polyswitch
Onboard dedicated power fuse helps prevent USB port failure. It prevents USB Port overcurrent and safeguards your system and device lifespan.
OC / OV / OH Protection
All BIOSTAR special circuit design detects overvoltage conditions and prevents voltage surges from spreading in real time. It also actively cuts off the overvoltage supply to protect your system. Over current protection helps avoid motherboard from damage when doing overclock or an unusual current import. Over heat protection helps avoid motherboard & CPU from burning when exceeding the temperature limitation.
DVI
DVI is better than VGA for LCD displays since it is digital while VGA is analog. For LCD displays, the picture is digitized pixel per pixel. Through DVI, the panel gets data for each pixel, so the picture generated in the Graphics device matches the pixels on the panel itself.
PRODUCT SPECIFICATIONS
| Chipset | Intel B250 |
| CPU SUPPORT | Intel® Core¿ i7 LGA 1151 Processor
Intel® Core¿ i5 LGA 1151 Processor
Intel® Core¿ i3 LGA 1151 Processor
Intel® Pentium® LGA 1151 Processor
Intel® Celeron® LGA 1151 Processor
Maximum CPU TDP (Thermal Design Power) : 95Watt |
| MEMORY | Support Dual Channel DDR4 2400/ 2133/ 1866 MHz
2 x DDR4 DIMM Memory Slot
Max. Supports up to 32GB Memory
* DDR4 2400 for 7th Generation Intel® Core¿ Processor Family |
| EXPANSION SLOT | 1 x PCI-E x16 3.0 Slot
5 x PCI-E x1 3.0 Slot(using for bitcoin mining, it is suggested to change to PCI-E 1.0 via BIOS) |
| STORAGE | 6 x SATA3 Connector
1 x M.2 Key M 32Gb/s Connector, support M.2 type 2242/ 2260/ 2280 SATA 6Gb/s & PCIe Storage |
| USB | 4 x USB 3.0 Port
1 x USB 3.0 Header
2 x USB 2.0 Port
2 x USB 2.0 Port(only 5V power, up to 1.5A)
2 x USB 2.0 Header |
| LAN | Realtek RTL8111H - 10/100/1000 Controller
Support Super LAN Surge Protection |
| INTEGRATED VIDEO | By CPU model
Supports DX12
Supports HDCP |
| CODEC | Realtek ALC887 8-Channel HD Audio
Support HD Audio |
| REAR I/O | 1 x PS/2 Mouse
1 x PS/2 Keyboard
4 x USB 3.0 Port
2 x USB 2.0 Port
2 x USB 2.0 Port(only 5V power, up to 1.5A)
1 x DVI-D Connector, resolution up to 1920 x 1200 @60Hz
1 x RJ-45 Port
3 x Audio Connector |
| INTERNAL I/O | 1 x USB 3.0 Header
2 x USB 2.0 Header
6 x SATA3 6Gb/s Connector
1 x SATA Power Connector(for rear USB power enhancement)
1 x M.2 Key M 32Gb/s Connector, support M.2 type 2242/ 2260/ 2280 SATA 6Gb/s & PCIe Storage
1 x Front Audio Header
1 x Front Panel Header
1 x CPU Fan Header
2 x System Fan Header
1 x Serial Header
2 x PCI-E 12V 4Pin Connector(Must be installed when using for bitcoin mining.) |
| H/W MONITORING | CPU / System Temperature Monitoring
CPU / System Fan Monitoring
Smart / Manual CPU Fan Control
System Voltage Monitoring |
| DIMENSION | ATX Form Factor Dimension: 29.5cm x 21cm ( W x L ) |
| OS SUPPORT | Support Windows 10(x64) for Intel 7th Generation Processor
¿Support Windows 7 / 8.1(x64) / 10(x64) for Intel 6th Generation Processor |
| BUNDLE SOFTWARE | BullGuard
Smart Speed LAN(Windows 7/ 8.1 only)
Intel Rapid Storage Technology |
| ACCESSORIES | 2 x SATA Cable
1 x I/O Shield
1 x DVD Driver
1 x User Manual |
| FEATURES | Supports 100% Solid capacitor
Supports Charger Booster
Supports BIOS Online Update |
