| Chipset | Intel X79 |
| CPU SUPPORT | Intel® Core™ i7 LGA 2011 Processor Maximum CPU TDP (Thermal Design Power) : 150Watt |
| MEMORY | Support Quad Channel DDR3 2400(OC)/2133(OC)/1866(OC)/1600/ 1333 /1066 MHz 4 x DDR3 DIMM Memory Slot Max. Supports up to 32GB Memory |
| EXPANSION SLOT | 3 x PCI-E x16 3.0 Slot (x16, 16, x8 )4 WAY CFX, 3 WAY SLI 2 x PCI-E x1 2.0 Slot 1 x PCI Slots |
| STORAGE | 4 x SATA3 Connector 3 x SATA2 Connector 1 x eSATA2 Connector Support SATA RAID: 0,1,5,10 |
| USB | ASMedia ASM1042 USB 3.0 controller 6 x USB 3.0 Port 1 x USB 3.0 Header 2 x USB 2.0 Port 2 x USB 2.0 Header |
| LAN | Realtek RTL8111E - 10/100/1000 Controller |
| MULTI GRAPHICS | AMD 4-Way CrossFireX NVIDIA 3-Way SLI |
| CODEC | Realtek ALC898 8 Channel Blu-ray Audio |
| REAR I/O | 1 x PS/2 Keyboard 1 x eSATA2 Connector 6 x USB 3.0 Port 2 x USB 2.0 Port 1 x RJ-45 Port 6 x Audio Connector 1 x S/PDIF Out Port |
| INTERNAL I/O | 1 x USB 3.0 Header 2 x USB 2.0 Header 4 x SATA3 6Gb/s Connector 3 x SATA2 3Gb/s Connector 1 x Front Audio Header 1 x Front Panel Header 1 x S/PDIF-OUT Header 1 x CPU FAN Header 2 x System FAN Header 1 x Serial Header 1 x CIR Header |
| DIMENSION | ATX Form Factor Dimension: 30.5cm x 24.4cm ( W x L ) |
| OS SUPPORT | Support Windows XP / Vista / 7 |
| ACCESSORIES | 6 x SATA Cable 1 x SLI Connector 1 x CrossFire Connector 1 x I/O Shield 1 x CD Driver 1 x User Manual |
| FEATURES | Supports uEFI GUI Interface BIOS Supports THX TruStudio Pro Supports BIO-Remote2 Supports BIO-Remote Supports Space-Pipe Thermal solution Supports 100% Solid capacitor Supports Puro Tone HD Audio Technology Supports Rapid Switch2 Supports Rapid Debug3 Supports BIOS-Flasher Supports Toverclcoker OC software Supports Charger Booster |
