BIXOLON XD3-40d Direct Thermal Label Printer Compact, Fast & Cost-Effective
The BIXOLON XD3-40d is a high-performance 4-inch desktop label printer designed for fast-paced environments like retail, logistics, healthcare, and warehousing. Using direct thermal technology, it eliminates the need for ribbons, reducing operational costs and simplifying maintenance.
With print speeds up to 5 inches per second, USB connectivity, and support for multiple media types, the XD3-40d delivers crisp, reliable labels for shipping, inventory, and product identification. Its user-friendly design includes tool-free maintenance, adjustable paper guides, and drop-in media loadingmaking it ideal for businesses seeking efficiency and durability.
Key Features:
- Direct thermal printing no ribbon required
- Fast print speeds up to 5 ips (127 mm/sec)
- 203 dpi resolution for sharp, clear labels
- Supports media widths from 15 to 118 mm
- Easy paper loading with adjustable guides
- USB interface (standard); optional Ethernet & Serial
- Compatible with major programming languages (SLCS, BPL-Z, BPL-E, BPL-D)
- ENERGY STAR® certified for eco-efficiency
- Toolless maintenance of print head and roller
- Optional peeler and external paper supply
Ideal For: Retail price tags, shipping labels, inventory tracking, patient wristbands, and barcode labeling in logistics and healthcare.
Technical Specifications XD3-40d (Direct Thermal)
Category | Specification |
|---|
Print Method | Direct Thermal |
Print Speed | Up to 5 ips (127 mm/sec) |
Print Resolution | 203 dpi |
Max Print Width | 104 mm |
Max Print Length | 1,000 mm |
Sensors | Transmissive (Fixed), Reflective (Adjustable), Head Open |
Media Types | Gap, Black Mark, Notch, Continuous, Fan-Fold |
Media Width | 15 ~ 118 mm |
Media Roll Diameter | Up to 127 mm |
Media Thickness | 0.06 ~ 0.20 mm |
Supply Method | Easy paper loading |
Inner Core Diameter | 25.4 ~ 38.1 mm |
Interface | Standard: USB; Optional: USB + Serial + Ethernet |
Memory | 64 MB SDRAM, 128 MB Flash |
Dimensions (WxDxH) | 181 × 222 × 168 mm (7.13 × 8.74 × 6.62 inch) |
Weight | 1.7 kg (3.75 lbs.) |
Power Supply | External Adaptor 100240V AC, 50/60Hz |
Operating Temp | 0 ~ 40°C (32 ~ 104°F) |
Humidity Range | Operating: 10 ~ 80% RH; Storage: 10 ~ 90% RH |
Software Support | Windows/Linux/Mac drivers, OPOS, Bartender Ultralite, Label Artist-II |
SDKs Available | Windows SDK, Linux SDK |
Barcode Support | 1D: Code 39, Code 128, EAN-13, UPC-A, etc.
2D: QR Code, PDF417, DataMatrix |
Fonts & Graphics | Bitmap, Scalable, Unicode (UTF-8, UTF-16), User-defined logos & formats |
Certifications | ENERGY STAR®, RoHS compliant |
Warranty | 2 Year Manufacturer's Carry-In warranty |
