Product Parameters:
Input voltage: DC6-60V (the specific voltage is equal to the rated voltage of the motor)
Output voltage: linear under load
Output current: 0-30A
Continuous current: within 20A
Speed regulation type: current regulation
Speed regulation type: encoder knob 360 degrees
Speed regulation range: 0-100%
Setting frequency: 1-100KHZ can be set
Slow start and stop: can be set
Speed digital display: 0-100 percentage table
Wiring type: fence type terminals
Support motor: brush motor
Module size: L*W*H 96mm*61mm*34mm
Product net weight: 105g
Panel opening: L*W 92mm*56mm
Installation: Embedded
Product Features:
1. Knob with start/stop function
2. Slow start/stop time can be set
3. Limit the upper and lower speed limit
4. Frequency 1-100KHZ can be set
