Parameter:
Input/output interface: 20A high current 2P terminal
Instrument working voltage: XH-2.54-2P red and black wires, independent power supply DC6~30V Common power supply DC6~120V
Voltage measurement range: DC0~120V
Current measurement range: 0.00A~20.00A
Capacity measurement range: 0~9999.99Ah
Electricity metering range: 0~9999.99Wh
Impedance measurement range: 0~9999.99
Temperature measurement range: 0~99
Time measurement range: 0~999:59:59 (hour:minute:second)
Data reset: support
No-load return to zero: support
Voltage fine-tuning: support
Current trimming: support
Percentage power display: Supports percentage power based on voltage reference (full power and no power voltage need to be manually set)
Product size: 47.59 × 28.67 × 25.33mm
Installation hole: 45×26mm
Product weight: 26g
XH-2.54-2P red and black wi
