Specification:
Input Impedance: 1 Megaohm (1M)
Output Impedance: 50 Ohms (50)
Gain: 0 dB
Bandwidth: 300 MHz
Power Supply: 5V
Built-in Battery Capacity: 800mAh
Charging Current: 600mA
Operating Time: Over 24 hours
Dimensions: 50 x 45 x 18mm
Features:
1. High Impedance Matching: This amplifier serves as an impedance conversion device, transforming high input impedance to a standard 50-ohm output impedance. It is ideal for impedance matching and isolation in passive antenna reception setups, such as loop antennas, whip antennas, and magnetic rod antennas.
2. Versatile Compatibility: Suitable for a wide range of radio receivers and devices, including SDRs, walkie-talkies, HackRF One, and more. It can be used with various antenna types, including Donut antennas, Mini Loops, and tuned loo
