Specifications:
Operating Voltage Range: 6-36V
Maximum Output Current: 8A (low power version) / 15A (high power version)
Module Self-Consumption: Approximately 6mA
Switching Time: About 0.1ms
Dimensions: 46 x 32 x 15mm (L x W x H)
Operating Temperature: -40°C to +105°C
Material: Plastic + Metal
Features:
1. Equipped with high-power, low-loss MOSFETs for efficient performance.
2. Ultra-low power 8-bit MCU ensures swift and accurate switching between power sources.
3. Dual power indicators provide real-time power supply status monitoring.
4. Adjustable main power switching and recovery voltage via precision multi-turn potentiometer.
5. Lock-wire terminal design ensures secure and easy connection.
