Features:
It is suitable for occasions where online debugging is required to avoid damage to the target board due to the problem of Y capacitors in the computer power supply;
It is suitable for when the target board needs to work with electricity, so as to avoid damage to the computer port due to the power supply of the target board;
The isolation is safe and reliable, and it is not easy to damage the computer, target board or downloader due to static electricity;
Support SWIM interface;
Data and input/output power isolation;
The output power supply has short circuit protection function;
Compatible with 5V and 3.3V target boards.
Specification:
Dimensions: 54mm x 28mm x 16mm
Output Power: 5V/0.2A or 3.3V/0.2A
Isolation voltage: 1500V
Input interface: TypeC
Output interface: 2.54 DuPont line interface
Material: The shell is aluminum alloy / both ends are transparent plastic plates
Package Included:
1 x main unit
4 x 1P Dupont cable
