Specification:
- Physical Dimensions: 68*23.5*11.6mm (including plug)
- I/O Interface: XT60 Male/Female
- Applicable Detection Type: DC
- Detection Voltage Range: 5-34V
- Rated Current: 30A
- Maximum Instantaneous Current: 80A
- Startup Voltage: 4.5V
- Maximum Withstand Voltage: 36V
- Temperature Detection Range: 0-100% (relative)
- Temperature Detection Range: 0-80°C
- Ammeter Power Consumption: 5-12V, 0.3W, 13-34V, 0.5W
- Operating Temperature: 5°C to 35°C
- Operating Humidity: 20% to 80%
- Sampling Resistor: 1m
- Voltage Accuracy: +1% (default)
- Current Accuracy: +1% (default)
Features:
1. Built-in high-precision temperature and humidity sensor for real-time temperature and humidity monitoring, a great helper for engineering applications.
2. Utilizing a thickened
