BLUE DISPLAY 0-50A DC Digital display LED Panel Ammeter Meter (INCLUDES SHUNT)
Â
Newest version!
Â
Â
Feature
1. Size: 4.8 X 2.9 X 3.6 cm
2. open pore size: 4.6 X 2.7 cm
3. lead wire length:15cm
4. net weight: 30g
5. Measuring Range: DC0-50A(connect with 50A/75mV shunt)
6. Maximum Input: DC50A
7. Display: three 0.56â³LED digital tube
8. Display colors: blue
9. Refresh speed: about 500ms/each time
10. Allowable error: 1% (+ /-1)
11. Power supply: DC6-28V
12. Current consumption: Less than 20 mA, general 5-15 mA
13. Working temperature: -10 ~ 65
NOTE:
1. Must put the shunt in series of negative load,otherwise it will burn the meter.
Â
PRICE ABOVE IS FOR 1 ITEM
