Specifications:
Control System: PWM Pulse Control
Processor: Integration Digital Circuit Processor
Required Pulse: 3 to 5V peak square waves
Operating Frequency: 1520s/333Hz
Rotation Angle Sensor: High Precision Potentiometer
Rotation Angle: Left: 60°, Right: 60°
Voltage (DC): 3.5V to 7.4V
Temperature Range: -20 to 70
Operational Angle: 60 degrees at 600s
Running Direction: Clockwise/900s-2100s
Pulse Width Range: 900-2100s
Midpoint Pulse: 1500s
Speed (No Load): 0.06sec/60°@4.2V, 0.04sec/ 60° @ 6.0V
Torque (Stall full): 1.02 [email protected], 1.35 kg.cm @ 6.0V
Standby Current/Ampere: 0.300A/4.2V, 0.300A/6.0V
Operating Current/Ampere: 0.300A/4.2V, 0.300A/6.0V
Stall Current/Ampere: 0.300 A/4.2V, 0.300 A/6.0V
Dead Width: 1s
Bearing: Center Oily Bearing
Bearing Specification: 1.5mm×4mm×1.5mm
Gear Material: Chrome-Titanium Alloy (7075+6061)
Shell
