BMS (3S-30A / 200580) Li-Ion, BMS Control Board, 3S, 30A, 10.8-12.6V

3 series or lithium battery protection boards, suitable for nominal voltage10.8V lithium batterypack, 11.1V lithium battery pack, 12.6V lithium battery pack. With automaticactivation function,the protection will be automatically cancelled after the protection conditionsare restored, withoutthe need for charger activation, which is more convenient to use.Module name: YH11047AOvercharge detection voltage: 4.25±0.025VOvercharge release voltage: 4.15±0.05VOver-discharge detection voltage: 2.50±0.08VOver-discharge release voltage: 3.00±0.1VOvercurrent current: 20-30AWorking current: 15A (nominal 10A), at 15A extra cooling is required, maximumpeek current 30A)Release condition: the protection condition is released and automaticallyrestored withoutactivation (optional charger activation)Main functions: overcharge protection, over-discharge protection, short circuitprotection,overcurrent protection.Working temperature: -40~+85 degrees (please strengthen heat dissipation whenthe ambienttemperature is too high)No part design on the back, can be attached to the heat sink to ensure thatlarge currents to worklong hours. Lift Condition: Protecting release the auto recovery, withoutactivation
