The Bose Professional sound quality you expect. The improvements you need. FreeSpace FS loudspeakers are the next step of our widely trusted line of in-ceiling and surface-mount loudspeakers, offering significant upgrades in durability, design, and ease of installation all with remarkably consistent tonality. Engineered for high-quality performance in both background music and voice announcement applications, FS loudspeakers are ideal for almost any commercial space. The line includes five loudspeakers, two distinct levels of sound, new mounting options, and a modern aesthetic to match. For those seeking consistent, quality installed sound, FreeSpace FS loudspeakers are the perfect mix of performance and value.
Features Full-range 2.25-inch transducer, low-frequency range down to 83 Hz, 16-ohm and 70/100V operation
Stylish pendant enclosure with single-point suspension, perfect for open-ceiling applications or any installation requiring the aesthetic and performance capabilities of a pendant design
Maintain consistent tonal quality with shared voicing across all FS models
Hear the best of both music and voice with transducers that offer clear voice reproduction and smooth response for background music
Blend with more room designs with updated enclosures available in black and white that pair modern aesthetics with practical features, including removable logos
Tackle site-specific challenges with the support of a full suite of accessories, designed to handle a wide range of applications and mounting options
Install with ease all models feature Euroblock inputs and front-baffle input location on in-ceiling models
Support public safety all models are UL 1480 ULC-S541-listed for use in fire alarm and signaling systems in life safety applications
Specifications Frequency Response (-3 dB)95 16,000 Hz
Frequency Range (-10 dB)83 19,000 Hz
Nominal Coverage Angle (1 - 4 kHz)140°
Nominal Coverage (1 10 kHz)130°
Power Handling, Long-term Continuous
AES transducer test: 20 W
Bose extended-lifecycle test: 16 W
Power Handling, Peak
AES transducer test: 80 W
Bose extended-lifecycle test: 64 W
Sensitivity SPL/1W @ 1 m
AES transducer test: 87 dB
Bose extended-lifecycle test: 87 dB
Calculated Maximum SPL @ 1 m
AES transducer test: 100 dB
Bose extended-lifecycle test: 99 dB
Calculated Maximum SPL @ 1 m, Peak
AES transducer test: 106 dB
Bose extended-lifecycle test: 105 dB
Loudspeaker EQ No Bose EQ required when speaker used for general use. Bose EQ Voicing and SmartBass available. EN54-24 Equalization is required for EN54-24 use; refer to FS2P EN54-24 Certified ratings document on pro.bose.com for details.
Recommended High-Pass Protection85 Hz with minimum 24-dB/octave filter
Transformer taps
70V: 1, 2, 4, 8, 16 W, bypass
100V: 2, 4, 8, 16 W, bypass
Transducers
Full-Range Driver: 1 × 2.25-inch woofer (57 mm)
Nominal Impedance: 16 ohms (transformer bypass)
Physical
Enclosure Material: Engineered plastics
Grille: Perforated steel, powder-coated finish
Logo: Removable
Color: Black (similar to Ral 9005), White (similar to Ral 9003)
Environmental: Indoor only
Safety Agency
Certification: EN54-24:2008 for Voice Alarm Systems, UL 1480 UUMW, CAN/ULC-S541 UUMW7 for
Speakers for Fire Alarm and Signaling Systems. Installation: NFPA 70, NFPA 72, CSA C22.1 Section 32.
For EN54-24 specifications, Refer to FS2P EN 54-24 Certified Ratings document on pro.bose.com.
EN54-24 Equilization required for EN54-24 use.
Operating Temperature Range0 °C to 50 °C (32 °F to 122 °F)
Connectors
Euroblock 6-pin connector with loop-through, mounted on top. Accepts 18 AWG (0.8 mm2) to 14
AWG (2.5 mm2) size wire. Includes input cover.
Suspension/Mounting
Each FS2P has one (1) suspension attachment point and one (1) safety cable attachment point
Included is one (1) 4.5 m (15 ft) adjustable pendant suspension cable
Product Dimensions (Enclosure Diameter × Depth)149 × 183 mm (5.9 × 7.2 in)
Product Dimensions with Suspension Cable Attachment Point (Enclosure Diameter × Depth)5.9 × 8.5 inches (149 × 215 mm)
Net Weight, Loudspeaker with Grille (Single)3.25 lbs (1.47 kg)
Shipping Weight (Pair)8.95 lbs (4.06 kg)
