BOSS BD-2W WAZA CRAFT BLUES BLUES DRIVER, MADE IN JAPAN

Special edition Waza Craft pedal delivers the ultimate BOSS tone experience
Premium sound based on the classic BD-2 Blues Driver
Newly revised, all-analog discrete amplifier circuit
Standard and Custom sound modes
Highly responsive to picking dynamics and volume changes
BOSS five-year warranty

Specifications
Nominal Input Level
-20 dBu
Input Impedance
1 M ohm
Nominal Output Level
-20 dBu
Output Impedance
1 k ohm
Recommended Load Impedance
10 k ohms or greater
Controls
Pedal switch
Mode switch
LEVEL knob
TONE knob
GAIN knob
Indicator
CHECK indicator (Serves also as battery check indicator)
Connectors
INPUT jack
OUTPUT jack
DC IN jack
Power Supply
Alkaline battery (9 V, 6LR61) or Carbon-zinc battery (9 V, 6F22)
AC adaptor (sold separately)
Current Draw
18 mA
Expected battery life under continuous use
Carbon: Approx. 20 hours
Alkaline: Approx. 35 hours
*These figures will vary depending on the actual conditions of use.
Accessories
Leaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTE," and "Information")
Carbon-zinc battery (9 V, 6F22)
Option (sold separately)
AC adaptor (PSA series)
Size and Weight
Width
73 mm
2-7/8 inches
Depth
129 mm
5-1/8 inches
Height
59 mm
2-3/8 inches
Weight
430 g
1 lb
