Bourns (3224J-1-103E) Trimpot, Multi Turn, Cermet, Side Adjust, 10 kohm

Trimpot, Multi Turn, Cermet, Side Adjust, 10 kohm, Surface Mount, 12 TurnsProduct InformationTrack Resistance: 10kohmTrimpot Type: Multi TurnElement Material: CermetAdjustment Type: Side AdjustPower Rating: 250mWPotentiometer Mounting: Surface MountResistance Tolerance: ± 10%No. of Turns: 12TurnsTemperature Coefficient: ± 100ppm/°CProduct Range: 3224Trimpot Shape / Size: 4 mm SquareResistor Case / Package: SMDProduct Length: 4.8mmProduct Width: 4.6mmProduct Height: 3.71mmOperating Temperature Min: -65°COperating Temperature Max: 150°CQualification: AEC-Q200Product OverviewThe Bourns Trimpot 3224 series are cermet, surface mount trimmingpotentiometers. These potentiometers are multi-turn which performs a variety ofcircuit adjustments in all types of electronic equipment. Typical applicationsare measuring linear distance, angle or rotation in production equipments.4mm square potentiometer meets EIA/EIAJ/IPC/VECI SMD standard trimmer footprintSide or top adjustment with lead screwSealed to withstand board wash processing12 turns and rotational life of 200 cyclesResistance value ranges from 10 ohm to 2Mohm±10% toleranceTemperature coefficient is ±100ppm/°COperating temperature ranges from -65°C to +150°CPower rating is 0.25WPick and place centring design with flush adjustment
