Bourns (3224W-1-102E) Trimpot, Multi Turn, Cermet, Top Adjust, 1 kohm

Trimpot, Multi Turn, Cermet, Top Adjust, 1 kohm, Surface Mount, 12 TurnsProduct InformationTrack Resistance: 1kohmTrimpot Type: Multi TurnElement Material: CermetAdjustment Type: Top AdjustPower Rating: 250mWPotentiometer Mounting: Surface MountResistance Tolerance: ± 10%No. of Turns: 12TurnsTemperature Coefficient: ± 100ppm/°CProduct Range: 3224Trimpot Shape / Size: 4 mm SquareResistor Case / Package: SMDProduct Length: 4.8mmProduct Width: 3.5mmProduct Height: 5.1mmOperating Temperature Min: -65°COperating Temperature Max: 150°CQualification: AEC-Q200Product OverviewThe 3224W-1-102E is a SMD Trimpot® Trimming Potentiometer with surface mount 4mmsquare/multiturn cermet/industrial/sealed and halogen free. Sealed to withstandboard wash processing and pick and place centring design, with flush adjustment.Power rating of 0.25W and temperature coefficient of ±100ppm/°C.Low CRV-1%600V Dielectric strength100MR Insulation resistanceUL94V-0 Flammability4mm Design meets EIA/EIAJ/IPC/VECI SMD standard trimmer footprintAdjustment angle 12 turnsTemperature coefficient is ±100ppm/°COperating temperature ranges from -65°C to +150°CPower rating is 0.25WPick and place centring design with flush adjustment
