Bourns (4605X-101-472LF) Fixed Network Resistor, 4.7 kohm, Bussed

Fixed Network Resistor, 4.7 kohm, Bussed, 4 Elements, SIP, 5 Pins, PC PinProduct InformationResistance: 4.7kohmNo. of Elements: 4ElementsNetwork Circuit Type: BussedResistor Case / Package: SIPNo. of Pins: 5PinsVoltage Rating: 100VResistor Terminals: PC PinPower Rating per Element: 200mWResistance Tolerance: ± 2%Temperature Coefficient: ± 100ppm/°CProduct Range: 4600XAutomotive Qualification Standard: -Product OverviewThe 4605X-101-472LF is a thick film Bussed Resistor Network with superiorpackage integrity and compatible with automatic insertion equipment, ConformalSIP package of epoxy resin body material, incorporates 3 to 13 thick-filmresistors of equal value, each connected between a common bus (pin 1) and aseparate pin. Bourns® resistor networks help space-sensitive applications byminimizing space, reducing costs, increasing board yields and reliability byreducing component count.10000MR Insulation resistance200Vrms Dielectric withstanding voltageUL94V-0 FlammabilityTemperature coefficient is ±100ppm/°C and ±250ppm/°C availableOperating temperature ranges from -55°C to +125°CLow profile is compatible with DIP packageWide assortment of pin packages enhances design flexibilityRecommended for rosin flux and solvent clean or no clean flux processes
