Bourns (PTL30-15G1-103B1) Slide Potentiometer, Slide, Standard Type

Slide Potentiometer, Slide, Standard Type with LED, 10 kohm, ± 20%, 100 mW,Linear, Through HoleProduct InformationSlide Potentiometer Type: Standard Type with LEDTrack Resistance: 10kohmResistance Tolerance: ± 20%Power Rating: 100mWTrack Taper: LinearPotentiometer Mounting: Through HoleLength of Travel: 30mmLever Length: 15mmResistor Technology: CarbonPotentiometer Terminals: PC PinProduct Range: PTLProduct Length: 45mmProduct Width: 9mmProduct Height: 7mmOperating Temperature Min: -10°COperating Temperature Max: 55°CProduct OverviewThe PTL30-15G1-103B1 is a Slide Potentiometer with LED and carbon element.Linear, audio taper & Power rating of 60mW and sliding life 15000 cycles.Red, orange, green, amber and white LED coloursCentre detent optionAssortment of resistance tapersVarious travel lengthsVarious lever sizes100MR Insulation resistance100mV Sliding noise300V Dielectric withstand voltage
