BY063 GP VB - Gx44 Battery (Second Stock) Sealed Lead Acid 12V 44A

VB - GP Battery (Second Stock

• SPECIFICATIONSCells Per Unit
  • 6

  Voltage Per Unit

  • 12

  Capacity

  • 26 Ah @ 20hr-rate to 1.75V per cell @25C (77F)

  Weight

  • Approx. 8.45 kg (18.63 lbs)

  Maximum Discharge Current

  • 350A (5sec)

  Internal Resistance

  • Approx. 11m

  Operating Temperature Range

  • Discharge: -15C ~50C (5F ~122F)
  • Charge: -15C ~40C (5F ~104F)
  • Storage: -15C ~40C (5F ~104F)

  Nominal Operating Temperature Range

  • 25C ± 3C (77F ± 5F)

  Float Charging Voltage

  • 13.5 to 13.8 VDC /unit Average at 25C (77F )

  Recommended Maximum Charging Current Limit

  • 7.8A

  Equalization and Cycle Service

  • 14.4 to 15.0 VDC /unit Average at 25C (77F )

  Self Discharge

  • CSB Batteries can be stored for more than 6 months at 25C (77F)
  • Please charge batteries before using
  • For higher temperatures the time interval will be shorter

  Terminal

  • B1/B3/B3B-L terminal or Recessed type to accept M5 bolt

  Container Material

  • ABS(UL 94-HB) & Flammability resistance of (UL 94-V0) can be available upon request



  DIMENSIONS (Unit: mm (inch))

  Overall Height (H)

  • 125±1.5 (4.92±0.06)

  Container Height (h)

  • 122±1.5 (4.8±0.06)

  Length (L)

  • 166±2 (6.54±0.08)

  Width (W)

  • 175±2 (6.89±0.08)

) Sealed Lead Acid 12V 26A
