Camdenboss (CTB0118/2) Standard Terminal Block, Wire to Board, CTB0118

Standard Terminal Block, Wire to Board, CTB0118, 2 Contacts, 7.62 mm, TerminalBlock, PCBProduct OverviewThe CTB0118/2 is a 2-pole 500V/24A standard profile rising clamp Terminal Blockwith UL94-V0 flame retardant PA green moulding, tinned nickel plated brasspin/terminal, nickel plated brass wire clamp, M3 steel zinc plated screw, 7.62mmpitch, double interlocking mechanism for increased strength. It featuresprofessional rising clamp terminals and guided pin alignment. It accepts 0.2 to4.0mm² (30 to 12AWG) solid cable, 0.2 to 2.5mm² (30 to 12AWG) stranded cable.=3kV Dielectric strength6kV Impulse withstand voltage1.3mm Recommended PCB hole sizeApplicationsIndustrialProduct InformationProduct Range: CTB0118No. of Contacts: 2ContactsPitch Spacing: 7.62mmConnector Type: Terminal Block, PCBConnector Mounting: PCB MountWire Size AWG Max: 12AWGWire Size AWG Min: 30AWGContact Plating: Nickel Plated ContactsContact Material: Brass
