Storage Type: SD, SDHC or SDXC (UHS-I)card
Image Sensor Type: 22.3 x 14.9mm CMOS
Effective Pixels: approx. 24.2 megapixels, Aspect Ratio: 3:2, Low-Pass Filter: Built-in/Fixed
Sensor Cleaning integrated
Image Processor Type: IGIC 6
Lens Mount: F/EF-S
Focal Length: equivalent to 1.6x the focal length of the lens
Focusing Type: TL-CT-SIR with a CMOS sensor
AF System/Points: 9 cross-type AF points (f/2.8 at centre)
AF Modes: AI Focus, One Shot, AI Servo
AF Point Selection Automatic selection: 19 point AF
Manual selection: Single point AF or Zone AF
Selected AF Point Display: Indicated by a transmissive LCD in viewfinder and on top LCD panel and Quick Control screen
AF Lock : Locked when shutter button is pressed half way in One Shot AF mode.
AF Assist Beam : Intermittent firing of built-in flash or emitted by optional dedicated Speedlite
Manual Focus : on lens
Metering Modes: 7560-pixel RGB+IR metering sensor, Metering with the area divided into 63 segments (9×7)
- Evaluative (linked to all AF points)
- Partial (approx. 6.0% of viewfinder)
- Spot (approx. 3.5% of viewfinder)
- Center-weighted average
- Metering Brightness Range: EV 1-20 (at 23°C with 50mm f/1.4 lens ISO100)
AE Lock Auto: In One-shot AF mode with evaluative metering exposure is locked when focus is achieved.
Manual: By AE lock button in creative zone modes.
Exposure Compensation: +/-5 EV in 1/3 or 1/2 stop increments (can be combined with AEB).
AEB: 3 shots +/- 2 EV, 1/2 or 1/3-stop increments
ISO Sensitivity: AUTO(100-6400), 100-12800 in 1-stop increments, ISO can be expanded to H: 25600, During Movie shooting: Auto (100-6400), 100-6400 (Whole stop increments) ISO can be expanded to H: 12800
Shutter Type: Electronically-controlled focal-plane shutter, Speed: 30-1/4000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode)
White Balance Type: Auto white balance with the imaging sensor, Settings: AWB, Daylight, Shade, Cloudy, Tungsten, White Fluorescent light, Flash, Custom. Compensation: 1. Blue/Amber +/-9, 2. Magenta/ Green +/-9.
Custom White Balance: 1 setting can be registered
WB Bracketing: '+/-3 levels in single level increments, 3 bracketed images per shutter release.
Selectable Blue/Amber bias or Magenta/Green bias.
Viewfinder Type: Pentamirror, Coverage (Vertical/Horizontal): Approx. 95%, Magnification Approx. 0.82x, Eyepoint Approx. 19mm (from eyepiece lens centre), Dioptre Correction: -3 to +1 m-1 (dioptre)
AF information: AF points, focus confirmation light
Exposure information: Shutter speed, aperture value, ISO speed (always displayed), AE lock, exposure level/compensation, spot metering circle, exposure warning, AEB
Flash information: Flash ready, high-speed sync, FE lock, flash exposure compensation, red-eye reduction light
Image information: Highlight tone priority (D+), monochrome shooting, maximum burst (1 digit display), White balance correction, SD card information, Flicker Detection, focus area, electronic level
Depth of Field Preview: Yes, with Depth of Field preview button.
LCD Monitor Type: Touch screen vari angle 7.7cm (3.0") 3:2 Clear View II TFT, approx. 1040K dots, Coverage: Approx. 100%, Viewing Angle (Horizontally/Vertically): Approx. 170°
Brightness Adjustment: Adjustable to one of seven levels
Flash: Built-in Flash GN (ISO 100, meters): 12, Coverage: up to 17mm focal length (35mm equivalent: 28mm), Recycle Time: Approx. 3 seconds, Modes: Auto, Manual flash, Integrated Speedlite Transmitter
Red-Eye Reduction: Yes - with red-eye reduction lamp
X-Sync: 1/200sec
Flash Exposure Compensation: '+/- 2EV in 1/2 or 1/3 increments, Bracketing: Yes, with compatible External Flash, Lock: Yes
Second Curtain Synchronisation: Yes
Multi-Function Shoe/HotShoe/PC Terminal: Yes/No
External Flash Compatibility: E-TTL II with EX series Speedlites, wireless multi-flash support, Control: via camera menu screen
Shooting Modes: Scene Intelligent Auto (Stills and Movie), No Flash, Creative Auto, Portrait, Landscape, Close-up, Sports, SCN(Kids, Food, Candlelight, Night Portrait, Handheld Night Scene, HDR Backlight Control), Program AE, Shutter priority AE, Aperture priority AE, Manual (Stills and Movie)
Picture Styles: Auto, Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Defined (x3)
Colour Space: sRGB and Adobe RGB
Image Processing: Highlight Tone Priority, Auto Lighting Optimizer (4 settings),
- Long exposure noise reduction, High ISO speed noise reduction (4 settings),
- Multi Shot Noise Reduction, Auto Correction of Lens Peripheral illumination and
- Chromatic aberration correction, Basic+ (Shoot by ambience selection, Shoot by lighting or scene type), Creative filters (Art Bold, Water painting, Grainy B/W,
- Soft focus, Toy camera effect, Miniature effect, Fish-eye), Resize to M or S1, S2, S3
Drive Modes: Single, Continuous, Self timer (2s, 10s+remote, 10s + continuous shots 2-10)
Continuous Shooting: Max. Approx. 5fps. for approx. (speed maintained for approx. 940 images (JPEG), 8 images (RAW))
Live View Mode Type: Electronic viewfinder with image sensor, Coverage: Approx. 100% vertically and approx.100% horizontally, Frame Rate: 29.97 fps
Manual Focus (Magnify the image 5x or 10x at any point on screen)
Autofocus: Hybrid CMOS AF III (Face detection and Tracking AF, FlexiZone-Multi, FlexiZone-Single)
One-shot AF and Servo AF selectable for Stills and Movie
Real-time evaluative metering with image sensor.
Evaluative metering (315 zone), partial metering (10% of the Live View screen), spot metering (2.7% of the Live View screen), center-weighted average metering.
Still Image Type: JPEG: Fine, Normal (Exif 2.30 compliant) / Design rule for Camera File system (2.0),
- RAW (14bit, Canon original RAW 2nd edition),
- Digital Print Order Format [DPOF] Version 1.1 compliant
RAW+JPEG Simultaneous Recording: Yes (RAW + Large JPEG only)
Movie Type: MP4 (Video: H.264 (standard or lightweight: IPB), Sound: AAC, recording level can be manually adjusted by user). Movie Digital zoom available while shooting. Size: 1920 x 1080 (29.97, 25, 23.98 fps), 1280 x 720 (59.94, 50, 29.97 fps), 640 x 480 (29.97, 25 fps), HDR Movie (29.97fps, 25fps, 1280 x 720), Length: Max duration 29min 59sec, Max file size 4GB (new files will be created automatically)
Intelligent Orientation Sensor: Yes
Playback Zoom: 1.5x - 10x enabled in 15steps
Erase: Single image, All images in folder, Checkmarked images, unprotected images
Protection: Single image, all images in folder, all images on card
Firmware Update: Possible by the user.
Interface: Hi-Speed USB
Other: Video output (PAL/ NTSC) (integrated with USB terminal), HDMI mini output (HDMI-CEC compatible), External microphone (3.5mm Stereo mini jack)
