Image Sensor
Sensor
1/2.3-type CMOS
Filter
RGB Primary Color Filter
Total Pixels
Approx. 21.14MP
Effective Pixels per Sensor
Approx. 8.29 MP (3840 x 2160)
Subject Illumination Range
Approx. 0.3 lx to 100,000 lx
Minimum Illumination (PAL)
P (Program AE) Mode: Approx. 4.2 lx (shutter speed 1/25 sec with auto slow shutter On)
Low Light Mode: Approx. 0.3 lx (shutter speed 1/2 sec.)
Image Processor
Type
DIGIC DV 6
Colour Sampling
YCC 4:2:0 8bit
Lens
Zoom Ratio
20x Optical
Focal Length (35mm Equivalent)
Approx. 29.3 601mm Standard IS/IS Off
Minimum Focus Distance
1 cm at wide end, 60 cm across entire zooming range
Max. Aperture
f/1.8 2.8 (AV Priority and Manual Modes)
Aperture Blades
8 blades
Filter Diameter
58mm
Image Stabilization System
Optical system (lens shift) + electronic stabilization Dynamic, Standard, Powered IS, Off
ND Filter
Built-in gradation filter (Auto or Off)
Zoom Control
Zoom rockers on body and handle;
Selectable manual zoom/focus ring on lens;
Selectable High Speed and Soft Zoom modes available.
Zoom Speed
Variable (body rocker only) or Constant speed (body and handle rocker; Fast/Normal/Slow, 16 speed level settings in each)
Focus Control
MANUAL: Lens ring and touchscreen point selection (Magnify and Peaking assist functions), Focus Preset.
AUTOFOCUS: Touchscreen AF point selection, Face Detection and Tracking, Touch and Track, Face Only AF. (Instant AF, Medium AF, Normal AF)
Focus System
Hybrid AF (High Speed/Medium speed). Uses combination of TTL-video signal detection system and external phase difference metering system.
Normal AF. TTL, Contrast based AF
Iris Control
Touchscreen, Auto
Digital Zoom/Teleconverter
20x digital zoom (400x with optical zoom) and 40x digital zoom (800x with optical zoom) are available. Digital zoom not available in AUTO mode. 2x Digital Teleconverter
Recording
Video Storage Media
SD/SDHC/SDXC card (2 card slots)
Recording Time
150Mbps: 55 mins / 35Mbps: 240 mins / 17Mbps: 495 mins
Recording File System
FAT32/exFAT
Internal Recording Format (PAL)
XF-AVC:
3840 x 2160 / 25.00P (160 Mbps)
1920 x 1080 / 50.00P, 50.00i, 25.00P (45 Mbps)
MP4:
3840 x 2160 / 25.00P(150 Mbps)
1920 x 1080 / 50.00P, 25.00P (35, 17 Mbps)
External Recording Output
HDMI output (When Shooting):
UHD recording mode:
1920 x 1080 / 25.00P, 50.00P (for Slow&Fast), 50.00i (PsF mode); 1280 x 720 / 50.00P YCC 4:2:2 8-bit
Full HD recording mode:
1920 x 1080 50.00P/25.00P/50i ; 1280 x720 50.00P YCC4:2:2 10-bit
Slow/Fast Motion (PAL)
3840 x 2160 / 25.00P: x2, x4, x10, x20, x60, x120, x600, x1200
1920 x 1080 / 50.00P: x2, x4, x10, x20, x60, x120, x600, x1200
1920 x 1080 / 25.00P: x0.5
Pre-Record Function
Yes. 3 seconds
Still Photos
JPEG up to 3840×2160
(Still image resolution is dependent on the video resolution)
Photo Storage Media
SD Card
System
Display Type
Capacitive LCD touch panel
Size
3.5-inch (8.8 cm) on the diagonal, approx. 2,760,000 dots (1280 x RGB x 720)
Wave Form Monitor
No
Focus Assist
Peaking / Magnify
Peaking
Selectable Peaking Color: Red / Blue / Yellow
Zebra
70% or 100% reference level
Markers
Grid (white/grey), Level (white/grey), 4:3 (white/grey)
EVF
Size
0.36-inch (0.92 cm on the diagonal), Approx. 1,770,000 dots (1024 x RGB x 576)
Correction Lens
