Two power options:
1)Use built-in Li-ion battery
DVR can be activated after it has been placed on the vehicle by pressing the Power Switch for 3 seconds and turn off by pressing it again,
Charging: connect with USB cable or car charger.The indicator display red and convert to no light when it is full.
2)Connect with car charger
DVR will record automatically when the car starts,turn off and save the last file when the car stops.
Recording
DVR will enter into defaulted recording mode when turn it on,the work indicator blickers and indicates it is recording.The recording file is saved in the SD/MMC Card.To stop,press Recording Button or ending when car stops,the work indicator won’t blicker.
Camera mode
Turn on the DVR and press Mode Button to enter into Camera mode.To take photo by pressing SNAP Button.
Preview and Delete:
Turn on the DVR and press Mode Button twice to enter into Preview Mode,press Up or Down to select the previewed file.If it is video file,it can play or stop by pressing REC Button.If you want to delete it,press Menu Button to enter into delete mode,and then,select Single,All or Select by REC Button and UP/DOWN and confirm to delete the file by press REC Button.Also you can select Thumbnail mode and volume (from 1 to 8) under the Preview Mode.
Setting the functions:
Turn on the DVR and press Menu Button under Video mode or Camera mode to enter into setting interface.Confirm by REC Button and select by UP/DOWN for the following setting.Press Menu Button again to exit after finished.
A.Video mode:
1) Size: Select [1280*960/720*480/640*480 pixels]
2) Time Stamp: Select Off/Date only/Date&Time
3) Motion Detect:Select On/Off
4) Audio Record:Select On/Off
5) Recording time: Select [2/5/15] minute to decide how many time will be storage per one section.
B.Camera Mode:
6) Size: 1.3M/VGA
C.Setting Mode
Whether under video mode or capture mode,press Menu Button twice to enter into Setup interface.
7) Format: Select it if you want to format the SD card.
8) Language: Select [English/Chinese/Italian/Spanish/Portugues/German/French/Polish/Russian/Japanese/Korean].
9) System Reset:Select [Cancel or Execute system] reset.
10) Light Frequency:Set [50/60 Hz]
11) Date input:Set correct recording date and time by Rec Button and Up/Down Button.
12) IR LED:Auto or Off.
USB Mode
Connect DVR with computer by USB cable,[My computer] will occur removable disk,the file is stored at Removable Disk/DCIM/100DSCIM. At the moment,the file of the DVR can be downloaded to the computer.
