Key Features
Overview:
STest-896 (IV) CCTV tester with optical power meter
Ten-One CCTV security tester Combine the video test, Optical Power Meter , PTZ controller, video signal level test, NTSC/PAL color pattern generator, UTP cable test, PTZ protocol analysis, PTZ address scan, DC12 1A output, Audio test to one body.
The CCTV testerPRO STest-896 is developed for the On-Site installation and maintenance of video monitoring system. It can be used for displaying video, testing video level, controlling PTZ, scanning PTZ address, generating images, capturing data of RS485 and testing LAN cable etc. Its functions, easy operation, and portability makes it simple for the CCTV technician to install and maintain CCTV system, improving work efficiency and get the labor cost down.
STest-896 equipped with the Optical Power Meter. Use in testing the laser power of Video Fiber Optic Transmission equipment, and testing the Fiber Optic Patch Cord , etc.
STest-896 is an ideal multifunction Instrument for CCTV security system, Fiber Optical communication, CATV and other Fiber Optic works.
Features
3.5"TFT-LCD , 960(H) X 240(V) resolution
Optical power meter, testing the laser power of Video Fiber Optic Transmission equipment, and testing the Fiber Optic Patch Cord , etc.t.
DC12V power output
Audio input
Adjustable brightness, contrast, color of LCD
Video Level testing, video signals measured in IRE or mV
Automatically identify and adapt the video mode of NTSC and PAL
Colorbar Video signal generator, transmit/receive colorful images
Support more than twenty kinds of PTZ controller protocols. For example, PELCO-P, PELCO-D, SAMSUNG etc.
PTZ address scanning, search up the ID of PTZ camera.
Capture the PTZ protocol to assist the setting personnel to find out the control protocol and therefore easily target the problematic equipment.
Support RS232 and RS485 interface, the rate 150-19200bps
Powerful in testing LAN cable, measuring the connecting status and displaying the sequence of connection
PTZ(P/L & Zoom) Control: Control the status of P/L, zoom in/out the camera, adjust the aperture, foci and setting parameters, run and call the preset.
Lithium Ion Polymer Batteries(3.7V DC3000mAh), more reliable, and work 15 hours
Easy for use that the train is almost unnecessary
MODEL:STest-896 CCTV Security Tester
Video Test
Signal mode:NTSC/PAL (Auto Adjust)
Display
3.5 inch TFT-LCD ,960 x 240 resolution
LCD adjust:Adjustable brightness, contrast, color of LCD
Video IN/OUT:1 channel BNC Input & 1 channel Output
Video Output Mode:1.0 Vp-p
Video Level test
Level test:Video signals measured in IRE or mV
Power Output
Power output:DC12V, 1A
Audio Test
Audio input:1 channel Audio input
PTZ controller
Communication:RS232, RS422 simplex and RS485
PTZ Protocol:Compatible with more than 20 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc.customized
Baud Rate:150,300,600,1200,2400,4800,9600,19200bps
Video Signal Generation
Color bar generation:Output 1 channel color bar video signal for testing monitor
UTP Cable Test
UTP cable test:Test UTP cable connection state and display in the screen. Read the number of the test box.
PTZ data Capture and display
PTZ Data Test:Capture and Analyze the PTZ data sent from controlling device
PTZ address scanning :PTZ address scan Search up the ID of PTZ camera
Optical Power Meter
Optical Power Meter:testing the laser power of Video Fiber Optic Transmission equipment, and testing the Fiber Optic Patch Cord , etc.
Power
Power Adapter:DC5V, 2A
Battery:1 pcs Lithium Ion Polymer Batteries, 3.7V DC3000mAh
Rechargeable:4.5 hours recharging time, work for 12 hours
Low Consumption:Sleeping mode, display battery power state
Other Parameters
Work Temperature:-10âÂÂ---+50âÂÂ
Work Humidity:30%-90%
Dimension/Weight: 112mmx189mmx47mm / 500g
