CENTURION XTrac Tip-Up Garage Door Operator Kit

The XTrac Tip-Up Garage Door Operator has a quiet and powerful 24V DC motor that is connected directly to the garage door, travelling with it as it opens and closes. The XTrac can be set up in a few minutes and does not require any chains.

• Power lifting capability with 24V DC motor
• Quick & easy to install
• Battery backup allows continued use even during power outages
• Anti-crushing feature prevents door from closing if an obstruction is detected
• Equipped with onboard receiver with code-hopping security
• Includes wireless wall switch with 4 buttons that allow you to lock your garage door & control who has access to the garage

Centurion Systems is South Africa's leader in access automation. They manufacture an award-winning range of products used to control the access of vehicles and people in and out of residential and industrial properties. Centurion is known for its reliable products designed to maximise safety and convenience.

Click here to view all Centurion Systems products available in South Africa

Product specifications:

• Input voltage: 180V - 270V AC @ 50/60Hz
• Motor voltage: 24V DC
• Motor power supply - rated: 120W DC
• Motor supply: Dual power - 250VA maximum mains power supply, with 2 x 1.5Ah 24V DC battery backup supply
• Maximum door width: 6.5m
• Maximum door area: 12m²
• Maximum lifting capacity: 120kgf
• Operations in standby mode: 12 to 30 (dependent on door size, weight, height & duration of power failure)
• Opener travel speed: Adjustable between 90 - 125mm/sec
• Door travel adjustment: Manually adjustable limits with 1:1 adjustment
  ratio
• Safety obstruction force system: Selectable manual/adaptive
• Light: 24V 21W bayonet double-contact
• Autoclose: Dipswitch-selectable
• Infrared safety beams: Optional, but recommended
• Onboard receiver type: Code-hopping single channel
• Receiver code storage capacity: 22 transmitter buttons
• Receiver frequency: 433MHz

What you get:

• 1 x XTrac operator
• Mounting kit
• 2 x 1.5Ah batteries
• 2 x 4-button CENTURION transmitters
• 1 x 4-button wall switch
