CHIHAI CHF-GM1024-N20VA DC12V 105rpm 1:200 Ratio DC Motor Permanent Magnet Reduction Gear Motor CHIHAI CHF-GM1024-N20VA DC12V 105rpm 1:200 Ratio DC Motor Permanent Magnet Reduction Gear Motor CHIHAI CHF-GM1024-N20VA DC12V 105rpm 1:200 Ratio DC Motor Permanent Magnet Reduction Gear Motor
CHIHAI CHF-GM1024-N20VA DC12V 105rpm 1:200 Ratio DC Motor Permanent Magnet Reduction Gear Motor CHIHAI CHF-GM1024-N20VA DC12V 105rpm 1:200 Ratio DC Motor Permanent Magnet Reduction Gear Motor CHIHAI CHF-GM1024-N20VA DC12V 105rpm 1:200 Ratio DC Motor Permanent Magnet Reduction Gear Motor

CHIHAI CHF-GM1024-N20VA DC12V 105rpm 1:200 Ratio DC Motor Permanent Magnet Reduction Gear Motor

20 available / new
R486.00
Shipping
R35.00 Standard shipping using one of our trusted couriers applies to most areas in South Africa. Some areas may attract a R30.00 surcharge. This will be calculated at checkout if applicable.
Check my rate
The seller has indicated that they will usually have this item ready to ship within 12 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery
Main centres:  1-3 business days
Regional areas: 3-4 business days
Remote areas: 3-5 business days
Seller
Buyer protection
Returns
Replacement Guarantee: 7 Days: We stand by this guarantee
Get it now, pay later

Product details

Condition
New
Location
International
Bob Shop ID
645872281
Description:
CHIHAI CHF-GM1024-N20VA DC12V 105rpm 1:200 Ratio DC motor,permanent magnet reduction gear motor.

Specification:
Type CHF-GM1024-N20VA35Type
Shaft diameter 3mm, Dtype
Shaft length 10mm
Voltage 3-12V
Working voltage DC 12V
Power max 1.4W
Reduction ratio 1:200
No-load current a55A
No load speed 105RPM
Rated torque 1.0kg.cm
Rated speed 72RPM
Rated current a0.20A
Locked-rotor torque 2.6kg.cm
Locked-rotor torque max 3.0kg.cm (0.3N.m)
Locked-rotor current a0.45A
Application Office equipment, robot, camera rocker arm, home appliances.

Features:
1. High speed accuracy.
2. High strength and long life.
3. Convenient speed,low energy consumption, low noise.
4. Continuous operation, forward and reverse operation, stable operation, stable performance and low noise.
5. Compact structure and small size.
6. D type shaft : D type outlet shaft is more convenient for installation and is not easy to slip, saving installation time.
7. Adopt high-quality environmental-friendly copper stamping and shaping for many times, with beautiful appearance, light weight and never rusting.

Package Included:
1 XReduction gear motor
