The Cisco Meraki MR56 is a high-performance, cloud-managed Wi-Fi 6 indoor access point built for demanding enterprise environments. With 8x8 MU-MIMO in the 5GHz band and 4x4 MU-MIMO in the 2.4GHz band, it delivers ultra-fast connectivity, improved efficiency, and seamless multi-device performance.
Equipped with four concurrent radiosincluding dedicated security and Bluetooththis access point supports advanced features like real-time WIDS/WIPS, location analytics, Layer 7 traffic shaping, and WPA3 security. Designed for high-density deployments, the MR56 is ideal for offices, schools, hospitality venues, and retail spaces that demand reliable, high-speed wireless coverage.
Key Features & Benefits
Wi-Fi 6 (802.11ax) with up to 12 spatial streams for exceptional speed and capacity
8x8 MU-MIMO on 5GHz and 4x4 MU-MIMO on 2.4GHz for high-density environments
Four radios for simultaneous client access, security scanning, and Bluetooth services
Advanced security with WPA3, rogue AP containment, and PCI compliance reporting
Cloud-managed via Meraki Dashboard for simplified deployment and monitoring
Fanless design with silent operation and versatile mounting options
Ideal Uses
Enterprise offices requiring secure, high-performance wireless connectivity
Educational campuses supporting dense device environments
Hotels and hospitality venues providing seamless guest Wi-Fi
Retail environments needing reliable Wi-Fi for staff and customer devices
Specifications
Condition: device with no signs of previous use. Device has been tested and is fully functional.
Brand: Cisco Meraki
Model: MR56
Device Type: Indoor Access Point
Wi-Fi Standards: 802.11a/b/g/n/ac/ax
Radios:
2.4 GHz 802.11b/g/n/ax client access
5 GHz 802.11a/n/ac/ax client access
Dual-band WIDS/WIPS, spectrum analysis, and location analytics
2.4 GHz Bluetooth Low Energy (BLE) with beacon and scanning support
Antenna: Internal (5.4 dBi at 2.4GHz, 6 dBi at 5GHz)
MIMO: 8x8 MU-MIMO (5GHz), 4x4 MU-MIMO (2.4GHz)
Features: OFDMA, BSS Coloring, Beamforming, MRC, Packet Aggregation
Channel Widths: 20/40MHz (2.4GHz), 20/40/80MHz (5GHz)
Interfaces: 1 x 100/1000/2.5G/5G BASE-T (RJ45), 1 x DC power connector
Power: 802.3at PoE (42.557V) or 12V DC, 30W max
Security: WPA3-Personal/Enterprise, WPA2, WPA, 802.1X, VLAN tagging, IPSec tunneling, integrated Layer 7 firewall
Management: Meraki Cloud Dashboard (license required)
Mounting: Ceiling, wall, and desktop mounting hardware included
Environment: 0°C to 40°C operating, 595% RH non-condensing
Dimensions: 32.6 x 14.08 x 4.47 cm
Weight: 1 kg
Warranty: 6 Month Carry-in Warranty
What's in the Box: MR56 Access Point
